| # | Part | Description |
Req | Notes | Availability |
|---|
1a |
162-0003
|
6V 225Ah wet battery (SNSR) |
6 |
(includes 2) |
|
1b |
162-0005
|
6V 305Ah wet battery (SNSR) |
6 |
(includes 2) |
|
2 |
999-0211
|
Nut 5/16-18 hex nylon insert lock zinc plated |
2 |
|
|
3 |
275-5948
|
Battery terminal cover (black) |
12 |
(210-240AH) |
|
4 |
175-1103
|
Battery cable boot (black) |
12 |
|
|
5 |
998-0010
|
Battery jumper cable - ring type (red) |
5 |
|
|
6 |
375-4625
|
Cable assembly |
1 |
(includes 7) |
|
7 |
375-4626
|
Battery connector |
1 |
|
|
8 |
375-4627
|
Cable assembly |
1 |
(includes 9) |
|
9 |
375-4626
|
Battery connector |
1 |
|
|
10 |
175-2128
|
Battery spacer |
1 |
(210-240AH) |
|
11 |
175-2127
|
Battery spacer |
2 |
|
|
12 |
375-3320
|
4 gauge battery jumper cable 15 inch (red) |
1 |
|
|
