| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
999-1090
|
Screw M5-.8 x 10mm pan head phillips zinc plated |
$0.99
|
3 |
|
ships same day |
2 |
275-6817
|
Vacuum motor mounting plate |
$249.15
|
1 |
|
usually ships 5-16 days |
3 |
999-1084
|
Screw M6-1 x 16mm truss head slotted stainless steel |
$0.99
|
3 |
|
ships same day |
4 |
375-1323
|
Shroud with decal |
$177.87
|
1 |
(includes 5-6) |
usually ships 5-16 days |
5 |
175-1238
|
Moving parts decal |
$5.50
|
2 |
|
usually ships 5-16 days |
6 |
275-6172
|
Front decal (Nobles) |
$7.48
|
1 |
|
usually ships 1-5 days |
7 |
275-6818
|
Spacer |
$8.25
|
2 |
|
usually ships 1-5 days |
8 |
275-5085
|
Nut M6-1 x 16 hex head stainless steel |
$3.04
|
8 |
|
ships same day |
9 |
275-7366
|
Gasket |
$27.73
|
1 |
|
usually ships 5-16 days |
10 |
275-6585
|
12V 1 stage vacuum motor |
$305.91
|
1 |
|
usually ships 5-16 days |
11 |
175-7792
|
Vibration isolator |
$12.76
|
3 |
|
ships same day |
12 |
275-6819
|
Vacuum motor mounting bracket |
$8.47
|
1 |
|
usually ships 5-16 days |
13 |
175-7795
|
Cable tie |
$4.75
|
1 |
|
ships same day |
14 |
175-3401
|
Vacuum motor exhaust hose |
$72.60
|
1 |
|
ships same day |
15 |
275-6820
|
Vacuum hose assembly |
$80.52
|
1 |
|
usually ships 5-16 days |
16 |
997-2007
|
Hose clamp |
$2.07
|
1 |
|
ships same day |
