| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
275-7071
|
Cover |
1 |
|
|
2 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
2 |
|
|
3 |
999-0497
|
Nut M6-1 nylon insert lock stainless steel |
2 |
|
|
4 |
275-4847
|
Clamp plate |
1 |
|
|
5 |
175-5815
|
Screw 10 x 1/2 pan head phillips black |
2 |
|
|
6 |
275-7088
|
Cord hook |
2 |
|
|
7 |
275-7027
|
Screw M6-1 x 16mm truss head phillips |
4 |
|
|
8 |
275-7089
|
Onboard charger harness |
1 |
(includes 9) |
|
9 |
991-2105
|
SB50 50amp charger plug with pins (gray) |
2 |
|
|
10 |
275-7090
|
Fastener (Tennant Industrial) |
1 |
|
|
11 |
275-7091
|
36V onboard charger kit |
1 |
(includes 12-13) |
|
12 |
275-7092
|
15amp fuse |
1 |
|
|
14 |
999-0998
|
Washer #10 flat stainless steel |
4 |
|
|
15 |
999-1026
|
Washer #10 internal lock stainless steel |
4 |
|
|
16 |
175-3382
|
Bolt M5-.8 x 25mm hex head stainless steel |
4 |
|
|
17 |
999-1040
|
Screw M3-.5 x 20mm pan head |
2 |
|
|
18 |
999-0148
|
Washer #6 external star lock zinc plated |
2 |
|
|
