| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
175-2028
|
Gasket |
$8.91
|
1 |
|
usually ships 5-16 days |
2 |
175-2751
|
Tube adapter |
$100.10
|
1 |
|
usually ships 5-16 days |
3 |
175-2752
|
Tube adapter spring |
$6.60
|
1 |
|
ships same day |
4a |
175-1021
|
Tube mounting bracket |
$93.83
|
1 |
|
usually ships 5-16 days |
4b |
N/A
|
Not available |
Call for price
|
1 |
(Tube Mounting bracket) (old style, replace with new style) |
usually ships 3-26 days |
5a |
175-2060
|
Vacuum hose with cuffs 1 1/2 x 24 inch |
$62.15
|
1 |
(OEM) (after 11-2001) |
usually ships 5-16 days |
5b |
993-2388
|
(K) HOSE VAC 1.5 X 24 inch W/ CUFFS |
$23.08
|
1 |
(NON-OEM) |
usually ships 1-3 days |
5c |
175-2060
|
Vacuum hose with cuffs 1 1/2 x 24 inch |
$62.15
|
1 |
(after 03-2006) |
usually ships 5-16 days |
6a |
175-1021
|
Tube mounting bracket |
$93.83
|
1 |
(after 11-2001) |
usually ships 5-16 days |
6b |
175-1022
|
Plate brush lift latch |
$16.28
|
1 |
(after 03-2006) |
usually ships 5-16 days |
7 |
999-0024
|
Washer 5/16 flat stainless steel |
$1.34
|
3 |
|
ships same day |
8 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
$0.99
|
4 |
|
ships same day |
9 |
999-0030
|
Bolt 5/16-18 x 5/8 hex head grade 5 zinc plated |
$1.14
|
4 |
|
ships same day |
10 |
999-0430
|
Nut 5/16-18 hex jam plain finish |
$0.99
|
2 |
|
ships same day |
11 |
175-3009
|
Round knob assembly |
$16.17
|
1 |
|
usually ships 1-5 days |
12 |
999-1032
|
Screw 1/4-20 x 5/8 hex head stainless steel |
$0.99
|
2 |
|
ships same day |
13 |
999-0632
|
Washer 1/4 split lock stainless steel |
$0.99
|
2 |
|
ships same day |
14 |
999-0016
|
Washer 1/4 flat plain finish |
$0.99
|
2 |
|
ships same day |
15 |
175-1022
|
Plate brush lift latch |
$16.28
|
1 |
|
usually ships 5-16 days |
