T12 Scrub Head Side Squeegee Assembly

#PartDescriptionPriceReqNotesAvailability
1a 275-7668 Right hand squeegee door casting $47.63 1 usually ships 10-16 days
1b 275-7669 Left hand squeegee door casting $63.03 1 usually ships 10-16 days
2 275-7341 Latch (yellow) $26.18 1 usually ships 10-16 days
3 275-2236 SPRING, EXTN, 0.75OD 0.10WIR 03.0L $49.50 1 usually ships 10-16 days
4 275-0485 Clevis pin $4.09 1 usually ships 1-5 days
5a 275-7670 Squeegee lift bellcrank $55.33 1 (right hand) ships same day
5b 275-7395 Squeegee lift bellcrank $55.99 1 (left hand) usually ships 10-16 days
6 175-3349 Sleeved bushing $12.65 2 ships same day
7 175-3347 Washer .61 thrust $5.50 4 ships same day
8 275-7671 T-nut M8 x 1 1/4 $13.31 2 usually ships 10-16 days
9 999-1324 Screw M8-1.25 x 20mm flat head stainless steel $0.99 2 ships same day
10 175-0637 Clevis pin $4.09 1 usually ships 10-16 days
11 175-2117 Cotter pin $4.88 1 ships same day
12a 275-7672 Right hand squeegee guide block $50.38 1 usually ships 10-16 days
12b 275-7155 Left hand squeegee guide block $50.38 1 usually ships 10-16 days
13 999-1224 Screw M6-1 x 20mm flat head phillips stainless steel $2.48 2 ships same day
14 999-0469 Nut M6-1 nylon insert lock zinc plated $1.32 2 ships same day
15 275-7394 Strap weldment $75.57 1 usually ships 10-16 days
16 275-7396 Latch $30.91 1 usually ships 10-16 days
17a 275-7673 Right hand side squeegee frame $62.70 1 usually ships 10-16 days
17b 275-7154 Left hand side squeegee frame $62.70 1 usually ships 10-16 days
18a 275-7674 Squeege blade side 22 1/2 inch linatex $53.68 1 (standard) usually ships 10-16 days
18b 275-7675 Squeegee blade side 22 1/2 inch urethane $81.07 1 (optional) usually ships 10-16 days
18c 275-7676 Squeegee blade side 22 1/2 inch gum $27.50 1 (optional) usually ships 10-16 days
19 375-7041 Gasket $49.15 1 usually ships 10-16 days
