T12 Scrub Head and Drive Motor Assembly - Disk

#PartDescriptionPriceReqNotesAvailability
1 675-9751 Scrubber disc head weldment $564.74 1 usually ships 5-16 days
2a 275-7640 36V electric motor $1,126.29 2 (includes 2b) (before SN 11056555) usually ships 5-16 days
2b 275-7641 Motor brush kit $26.51 2 (before SN 11056555) usually ships 1-5 days
3 999-0355 Washer 3/8 x 7/8 SAE flat stainless steel $0.99 8 ships same day
4 999-0785 Screw M8-1.25 x 30mm hex head stainless steel $2.09 8 ships same day
5 175-9525 Brush drive hub $189.86 2 ships same day
6 175-5356 Square keyway $4.09 2 ships same day
7 999-0501 Bolt M8-1.25 x 25mm hex head full thread stainless steel $2.64 2 ships same day
8 999-0355 Washer 3/8 x 7/8 SAE flat stainless steel $0.99 2 ships same day
9 999-1407 Washer 5/16 belleville $3.04 2 ships same day
10 275-7642 Front rubber skirt $19.25 1 usually ships 5-16 days
11 275-7643 Front retainer strip $9.57 1 usually ships 5-16 days
12 275-7644 Rear rubber skirt $16.28 1 usually ships 5-16 days
13 275-7645 Rear retainer strip $7.70 1 usually ships 5-16 days
14 999-0335 Washer 1/4 x 5/8 SAE flat stainless steel $0.99 11 ships same day
15 999-1087 Bolt M6-1 x 25mm hex head stainless steel $0.99 9 ships same day
16 999-0469 Nut M6-1 nylon insert lock zinc plated $1.32 9 ships same day
17 275-7646 Distribution tube $59.40 1 usually ships 1-5 days
18 275-6500 Solenoid valve (Tennant Industrial) $88.00 1 usually ships 5-16 days
19 999-1228 Screw M5-.8 x 10mm hex head stainless steel $0.99 6 ships same day
20 175-3421 Plastic fitting $4.88 1 usually ships 1-5 days
21 275-4940 3 foot PVC hose (Tennant Industrial) $48.51 1 ships same day
22 175-0199 Hose clamp $6.60 4 usually ships 5-16 days
23 175-6081 Hose clamp $4.84 1 ships same day
24 175-7808 1/2 inch insulated P clamp $4.75 2 usually ships 1-5 days
25 175-4744 90 degree elbow fitting $8.47 1 usually ships 5-16 days
26 275-7647 Clevis pin $14.08 2 usually ships 5-16 days
27 175-0532 Cotter pin $5.17 2 usually ships 5-16 days
28a 275-7326 MOTOR, ELE, 36VDC 0360RPM 1.00HP GEAR (Tennant Industrial) $1,088.50 2 (includes 28b-28d) (between SN 11056555 and SN 30000000) ships same day
28b 275-5341 Carbon brush (pkg of 4) $116.49 1 (between SN 11056555 and SN 30000000) usually ships 5-16 days
28c 375-6016 Motor bearing $28.79 1 (between SN 11056555 and SN 30000000) usually ships 5-16 days
28d 375-2621 Electric motor bearing Call for price 1 (between SN 11056555 and SN 30000000) usually ships 5-16 days
