414RS Seat Trailer Assembly

#PartDescriptionPriceReqNotesAvailability
1 475-7327 TRAILER ASSEMBLY C/W SWIVEL BOX (Tennant Industrial) $3,667.32 1 (CIN 116) usually ships 5-16 days
3 475-6044 GUIDE ROLLER - SMALL WIDE/BUSHED (Tennant Industrial) $103.37 4 (CIN 116) usually ships 5-16 days
4 475-5371 GUIDE, NYLON - SHORT (Tennant Industrial) $58.78 2 (CIN 116) usually ships 5-16 days
5 475-4505 DOWEL PIN -SOLID 6X12 (Tennant Industrial) $7.01 2 usually ships 5-16 days
6 475-4368 SCREW, CSK HD HEX SKT - M5 x 12 - ZN PTD (Tennant Industrial $1.80 2 usually ships 5-16 days
7 475-4835 END STOP (Tennant Industrial) $26.72 1 usually ships 5-16 days
8 475-5871 GUIDE, NYLON - LONG (Tennant Industrial) $109.22 2 (CIN 116) usually ships 5-16 days
9 999-1115 Washer M4 flat zinc plated $0.99 1 ships same day
11 475-5130 M12 X 130 HEX BOLT PTD. (Tennant Industrial) $35.91 1 usually ships 5-16 days
12 475-5448 SPACER - CASTOR PLATED=10 (Tennant Industrial) $50.94 1 usually ships 5-16 days
13 475-5739 SLEEVE - CASTOR (Tennant Industrial) $67.47 1 usually ships 5-16 days
14 275-7500 Thornguard and wheel assembly (TENNANT INDUSTRIAL) $375.92 1 (414RS) usually ships 1-5 days
15 475-6559 CASTOR FORK - WELDMENT (Tennant Industrial) $203.57 1 usually ships 5-16 days
16 475-4780 SEAL - SWIVEL BEARING 40X52X7 (Tennant Industrial) $27.56 1 usually ships 5-16 days
17 475-6013 BEARING - TAPER ROLLER (Tennant Industrial) $99.53 2 usually ships 5-16 days
18 475-5074 NUT, NYLOC - M12 - ZN PTD, YELLOW ZINC P (Tennant Industrial $34.40 1 usually ships 5-16 days
19 475-6485 MUDGUARD MOULDING (Tennant Industrial) $197.90 1 usually ships 5-16 days
20 475-4295 WASHER, FORM 'A' - M6 - ZN PTD 500E ZINC (Tennant Industrial $1.20 2 usually ships 5-16 days
21 475-4338 SCREW, HEX HD SET - M6 x 20 - ZN PLD GRA (Tennant Industrial $3.00 2 usually ships 5-16 days
22 475-5651 LATCH PEG ASSY (Tennant Industrial) $63.63 2 usually ships 5-16 days
23 475-6620 RELEASE LEVER ASSY (Tennant Industrial) $239.31 1 usually ships 5-16 days
24 475-5068 SIDE-BRUSH ADJUSTER LOCK CAP 263-YELLOW (Tennant Industrial) $34.40 1 usually ships 5-16 days
25 475-6470 LATCH SPRING ASSY (Tennant Industrial) $186.71 1 usually ships 5-16 days
26 475-5882 SPRING-PLUNGER ST/ST 10680 stainless (Tennant Industrial) $79.66 1 usually ships 5-16 days
27 475-5698 LOCKING PLUNGER ST/ST DWG.485 (Tennant Industrial) $67.30 1 usually ships 5-16 days
28 475-5070 PIN, SPRING TENSION - O3 x 24 LG EACH (Tennant Industrial) $34.40 1 usually ships 5-16 days
29 475-4331 NUT, THIN - M8 ZINC PLATED (Tennant Industrial) $5.00 6 (half height) usually ships 5-16 days
30 999-9143 Screw M8-1.25 x 35mm button $1.32 3 usually ships 11-24 days
31 475-4382 Washer, Form C - M16 (Tennant Industrial) $9.85 1 usually ships 5-16 days
32 475-5075 NUT, NYLOC - M16 ZINC PLATED (Tennant Industrial) $50.60 1 usually ships 5-16 days
33 475-5936 BEARING SEALING CAP (Tennant Industrial) $89.68 1 usually ships 5-16 days
34 475-5095 'O' RING BS224 70DEG (Tennant Industrial) $36.91 1 usually ships 5-16 days
35 475-5710 CAM WELDMENT - LOCKING PLUNGER (Tennant Industrial) $51.27 1 (for locking plunger) usually ships 5-16 days
36 475-5036 M6 X 90 HEX BOLT PLATED (Tennant Industrial) $33.07 1 usually ships 5-16 days
37 475-5083 BOLT, HEX HD - M10 x 100 - ZP ZINC PLATE (Tennant Industrial $34.40 2 usually ships 5-16 days
38 475-6764 SEAT UPRIGHT WELDMENT PLATED=1.50 (Tennant Industrial) $368.57 1 usually ships 5-16 days
39 475-5076 NUT, NYLOC THIN - M10 ZINC PLATED ZINC P (Tennant Industrial $34.40 1 usually ships 5-16 days
40 475-5028 NUT, NYLOC - M6 ZINC PLATED ZINC PLATED (Tennant Industrial) $33.07 1 usually ships 5-16 days
41 475-5029 NUT, NYLOC - M10 - ZN PTD 500E (Tennant Industrial) $43.92 2 usually ships 5-16 days
42 475-6846 SEAT MOULDING-unlighted (Tennant Industrial) $427.69 1 usually ships 5-16 days
43 275-7502 Padded seat (TENNANT INDUSTRIAL) $370.41 1 usually ships 1-5 days
45 275-7501 Rear reflector (TENNANT INDUSTRIAL) $28.24 2 usually ships 1-5 days
46 475-4796 REFLECTOR MOUNTING BRACKET PLATING=.75 (Tennant Industrial) $13.36 2 usually ships 5-16 days
47 475-6571 SEAT PLATE WELDMENT PLATED=1.00 (Tennant Industrial) $241.32 1 usually ships 5-16 days
48 999-1427 Screw M8-1.25 x 20mm button head stainless steel $1.43 2 ships same day
49 475-5079 SCREW, BUTTON HD HEX SKT - M8 x 16 - PTD (Tennant Industrial $34.40 1 usually ships 5-16 days
50 475-6429 ROLLER/AXLE ASSEMBLY - SMALL WIDE/BUSHED (Tennant Industrial $172.51 2 (CIN 116) usually ships 5-16 days
50a 375-5049 Medium roller axle Call for price 2 (CIN 115 only) usually ships 5-16 days
50b 375-5050 Large roller axle Call for price 2 (CIN 115 only) usually ships 5-16 days
51 475-5190 BUSH-FLANGED DU 16i.d. 17L GLY.PBG.16181 (Tennant Industrial $37.91 4 usually ships 5-16 days
52 475-5035 M4X12 C/SUNK SCREW PLATED (Tennant Industrial) $33.07 2 usually ships 5-16 days
53 475-4442 SCREW, BUTTON HD HEX SKT - M4 x 6 - ZP Z (Tennant Industrial $5.00 2 usually ships 5-16 days
