| # | Part | Description |
Req | Notes | Availability |
|---|
0 |
275-8240
|
Flashing light kit |
1 |
(includes 1a-11) |
|
1a |
275-8241
|
24V flashing light assembly (OBSOLETE) |
1 |
|
|
1b |
275-8242
|
Caution light |
1 |
|
|
2 |
999-1671
|
Screw M5-.8 x 20mm pan head phillips stainless steel |
2 |
|
|
3 |
999-0998
|
Washer #10 flat stainless steel |
2 |
|
|
4 |
999-0740
|
Nut M5-.8 hex stainless steel |
2 |
|
|
5 |
275-8243
|
Bracket |
1 |
|
|
6 |
275-8244
|
NUT, ISOLATOR, .25-20 WALL TH .031-.187 (Tennant Industrial |
4 |
|
|
7 |
999-0298
|
Bolt 1/4-20 x 1 1/4 hex head stainless steel |
4 |
|
|
8 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
4 |
|
|
9 |
175-4544
|
Washer M6 locking |
4 |
|
|
10 |
175-0005
|
Rocker switch |
1 |
(hazard light) |
|
11 |
175-0037
|
Wire tie |
1 |
|
|
