| # | Part | Description |
Req | Notes | Availability |
|---|
001a |
275-4159
|
CONTROLLER KIT [MAXPRO1000] (Tennant Industrial) (OBSOLETE) |
1 |
|
|
001b |
275-4160
|
Replacement controller kit (Tennant Industrial) (OBSOLETE) |
1 |
|
|
002 |
175-0568
|
GROMMET, RIBBON CABLE, .63 X 1.81 (Tennant Industrial) |
1 |
|
|
003 |
275-4161
|
COVER, CIRCUITBOARD (Tennant Industrial) (OBSOLETE) |
1 |
|
|
004 |
N/A
|
Not available |
1 |
PLATE, MTG, CIRCUITBOARD (Tennant Industrial)
|
|
005 |
N/A
|
Not available |
1 |
GASKET, CIRCUITBOARD, ADH (Tennant Industrial)
|
|
006 |
175-0873
|
PIN, PRONG, CIRCUITBOARD ASSY (Tennant Industrial) |
9 |
|
|
007 |
275-4164
|
GROMMET, RBR, 1.06ID, F/1.4H, .19 MATL (Tennant Industrial) |
1 |
|
|
008 |
175-3160
|
Horn |
1 |
|
|
009 |
275-4165
|
SHUNT (Tennant Industrial) (OBSOLETE) |
2 |
|
|
010 |
999-0518
|
Bolt M6-1 x 25mm hex head full thread zinc |
4 |
|
|
011 |
999-0006
|
Washer 3/16 flat zinc plated |
18 |
|
|
012 |
999-0238
|
Washer 1/4 internal star lock zinc plated |
8 |
|
|
013 |
999-0439
|
Nut M6-1 hex coarse thread |
8 |
|
|
014 |
999-1430
|
Screw M3.5-.6 x 12mm pan head phillips zinc plated |
2 |
|
|
015 |
999-1305
|
Washer M3 split lock stainless steel |
4 |
|
|
016 |
999-0768
|
Nut M3-.5 hex coarse thread plain finish |
4 |
|
|
017 |
999-1158
|
Washer #6 flat stainless steel |
4 |
|
|
018 |
175-2547
|
2.5amp circuit breaker |
1 |
|
|
019 |
175-5969
|
15amp circuit breaker (Tennant Industrial) |
2 |
|
|
020 |
275-2596
|
Circuit breaker boot (Tennant Industrial) |
3 |
|
|
021 |
175-2216
|
Diode plug |
3 |
|
|
022 |
275-4166
|
Controller cover gasket (Tennant Industrial) (OBSOLETE) |
1 |
|
|
023 |
275-4167
|
Ribbon 34 conductor cable (Tennant Industrial) (OBSOLETE) |
1 |
|
|
024 |
175-0759
|
ACTUATOR, 36VDC, 02.7STRK, 500LB (Tennant Industrial) |
1 |
|
|
025 |
275-4168
|
SHUNT, 3 STD MOTOR, YEL [SCB 515] (Tennant Industrial) |
1 |
|
|
