| # | Part | Description |
Req | Notes | Availability |
|---|
001a |
N/A
|
Not available |
1 |
Solution tank |
|
001b |
275-4135
|
HOSE KIT, DRAIN, SOLTN (Tennant Industrial) (OBSOLETE) |
1 |
Includes 002 - 008 |
|
002 |
175-3381
|
Plastic hose clamp 1.6 ID x .62 |
1 |
|
|
003 |
175-3387
|
Seal |
1 |
|
|
004 |
175-3389
|
Lid gasket |
1 |
|
|
005 |
175-3390
|
Drain tank cap 3.85 thread pye |
1 |
|
|
006 |
N/A
|
Not available |
1 |
HOSE ASSY, PVC, 1.3ID 1.7OD 09.8L (Tennant Industrial)
|
|
007 |
175-3391
|
Drain cap kit |
1 |
Includes 008 |
|
008 |
175-3392
|
Strap |
1 |
|
|
009 |
275-4137
|
SCREEN, SOAPBASKET (Tennant Industrial) (OBSOLETE) |
1 |
|
|
010 |
175-3384
|
Tank cap |
1 |
Includes 011 |
|
011 |
175-3385
|
Lid gasket |
1 |
|
|
012 |
175-3386
|
Insert cover |
1 |
|
|
013 |
175-3388
|
Drain cap gasket |
1 |
|
|
014 |
N/A
|
Not available |
1 |
Vinyl end cap |
|
015 |
175-2159
|
Hose clamp |
1 |
|
|
016 |
N/A
|
Not available |
2 |
Washer |
|
017 |
275-2281
|
GASKET, NEO, .12, 2.00ID, 5/2.8BC (Tennant Industrial) |
1 |
|
|
018 |
275-4138
|
COVER, ACCESS, TANK, SOLTN (Tennant Industrial) |
1 |
|
|
019 |
275-4139
|
HOSE ASSY, PVC, 0.8ID 1.0OD 68.0L (Tennant Industrial) |
1 |
|
|
020 |
N/A
|
Not available |
1 |
BRACKET, RETAINER (Tennant Industrial)
|
|
021 |
175-2254
|
Hose clamp |
1 |
|
|
022 |
175-0680
|
Strain plastic fitting |
1 |
|
|
023 |
175-0709
|
Plastic backhand fitting (OBSOLETE) |
1 |
|
|
024 |
175-0662
|
90 degree plastic fitting |
1 |
|
|
025 |
175-3409
|
Plastic fitting |
1 |
|
|
026 |
175-3410
|
Plastic fitting |
1 |
|
|
027 |
175-3408
|
Solution filter |
1 |
|
|
028 |
275-4140
|
Clear vinyl hose (OBSOLETE) |
1 |
|
|
