| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
275-2244
|
BRACKET WLDT, MTG, SQGE (Tennant Industrial) |
1 |
|
|
002 |
275-2245
|
BRACKET, HOSE, SQGE (Tennant Industrial) (OBSOLETE) |
1 |
|
|
003 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
2 |
|
|
004 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
2 |
|
|
005 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
2 |
|
|
006 |
275-2246
|
PIVOT (Tennant Industrial) (OBSOLETE) |
1 |
|
|
007 |
999-0774
|
Bolt M10-1.5 x 30mm hex head stainless steel full thread |
2 |
|
|
008 |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
7 |
|
|
009 |
999-1120
|
Nut M10-1.5 nylon insert lock stainless steel |
4 |
|
|
010 |
175-0790
|
SPRING, DSL, 1.00OD 0.50ID 2.00L (Tennant Industrial) |
1 |
|
|
011 |
999-1429
|
Bolt M10-1.5 x 60mm hex head stainless steel |
1 |
|
|
012 |
175-0791
|
Nut M10 x 1.5 hex flange |
1 |
|
|
013 |
N/A
|
Not available |
1 |
Caster bracket |
|
014 |
999-1372
|
Bolt M10-1.5 x 25mm hex head stainless steel |
2 |
|
|
015 |
275-2248
|
CASTER KIT, SEALED [3.0 DIM] (Tennant Industrial) |
1 |
|
|
016 |
275-2249
|
CASTER, SWIVEL, 3.0D 1.4W, .50-13 STEM (Tennant Industrial) |
1 |
|
|
017 |
175-2188
|
Washer |
1 |
|
|
018 |
999-0050
|
Nut 1/2-13 hex jam plain finish |
1 |
|
|
019 |
N/A
|
Not available |
2 |
|
|
020 |
999-0152
|
Nut 1/4-20 nylon insert lock zinc plated |
3 |
|
|
