| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
275-2217
|
BRACKET, MTG, LIFT LINK (Tennant Industrial) (OBSOLETE) |
1 |
|
|
002 |
999-1372
|
Bolt M10-1.5 x 25mm hex head stainless steel |
2 |
|
|
003 |
999-1120
|
Nut M10-1.5 nylon insert lock stainless steel |
2 |
|
|
004 |
275-2218
|
BRACKET ASSY, LIFT, HEAD (Tennant Industrial) (OBSOLETE) |
1 |
Includes 005 |
|
005 |
175-2099
|
Flanged bushing |
2 |
|
|
006 |
175-0755
|
Sleeve |
2 |
|
|
007 |
999-0501
|
Bolt M8-1.25 x 25mm hex head full thread stainless steel |
2 |
|
|
008 |
999-0024
|
Washer 5/16 flat stainless steel |
2 |
|
|
009 |
175-0753
|
ROLLER, V-GROOVE, 1.5D 0.72B 0.8L [STL] (Tennant Industrial |
2 |
|
|
010 |
175-2563
|
Sleeve |
2 |
|
|
011 |
175-2099
|
Flanged bushing |
4 |
|
|
012 |
999-1426
|
Screw M8-1.25 x 45mm hex head stainless steel |
2 |
|
|
