| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
275-2105
|
HOPPER [515SS] (Tennant Industrial) (OBSOLETE) |
1 |
|
|
002 |
275-2106
|
BRACKET, MTG, FLTR, PANL (Tennant Industrial) (OBSOLETE) |
1 |
|
|
003 |
275-2107
|
BRACKET (Tennant Industrial) (OBSOLETE) |
1 |
|
|
004 |
999-0501
|
Bolt M8-1.25 x 25mm hex head full thread stainless steel |
12 |
|
|
005 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
21 |
|
|
006 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
9 |
|
|
007 |
275-2108
|
BRACKET, MTG, BMPR, FRONT (Tennant Industrial) (OBSOLETE) |
2 |
|
|
008 |
275-2109
|
BRACKET, HPPR (Tennant Industrial) (OBSOLETE) |
1 |
|
|
009 |
275-2110
|
Hopper lip skirt (Tennant Industrial) (OBSOLETE) |
1 |
|
|
010 |
275-2111
|
BRACKET, RETAINER, HPPR LIP (Tennant Industrial) (OBSOLETE) |
1 |
|
|
011 |
275-2112
|
ARM WLDT, LIFT, HPPR (Tennant Industrial) (OBSOLETE) |
1 |
|
|
012 |
175-3335
|
Flanged bushing |
4 |
|
|
013 |
275-2113
|
BOLT, SHLD, .50D X 1.00, .38-16 (Tennant Industrial) |
2 |
|
|
014 |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
2 |
|
|
015 |
999-0114
|
Washer 1/2 SAE flat |
6 |
|
|
016 |
175-6922
|
Nut 3/8 - 16 hex lock |
6 |
|
|
017 |
275-2114
|
BUMPER WLDT, FRONT (Tennant Industrial) (OBSOLETE) |
6 |
|
|
018 |
275-2115
|
SCREW, HEX, .31-18 X 4.50, G5 (Tennant Industrial) |
2 |
|
|
019 |
999-0211
|
Nut 5/16-18 hex nylon insert lock zinc plated |
2 |
|
|
020 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
4 |
|
|
021 |
275-2117
|
Actuator bracket weldment (Tennant Industrial) (OBSOLETE) |
1 |
|
|
022 |
275-2118
|
Actuator bracket weldment (Tennant Industrial) (OBSOLETE) |
1 |
|
|
023 |
275-2119
|
36V actuator (Tennant Industrial) (OBSOLETE) |
1 |
|
|
024 |
275-3031
|
PIN, CLEVIS, 0.37D X 4.00L (Tennant Industrial) |
1 |
|
|
025 |
999-1429
|
Bolt M10-1.5 x 60mm hex head stainless steel |
6 |
|
|
026 |
999-1120
|
Nut M10-1.5 nylon insert lock stainless steel |
1 |
|
|
027 |
275-2120
|
ANGLE, SPPT, HPPR (Tennant Industrial) (OBSOLETE) |
1 |
|
|
028 |
N/A
|
Not available |
4 |
|
|
029 |
999-0770
|
Screw M8-1.25 x 30mm flat head socket stainless steel |
5 |
|
|
030 |
999-1087
|
Bolt M6-1 x 25mm hex head stainless steel |
5 |
|
|
031 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
5 |
|
|
