| # | Part | Description |
Req | Notes | Availability |
|---|
001a |
175-5868
|
Short clear filter bowl |
1 |
|
|
001b |
991-8575
|
Short bowl (clear) |
1 |
|
|
002 |
275-2026
|
Cable pulley assembly (Tennant Industrial) (OBSOLETE) |
1 |
|
|
003 |
N/A
|
Not available |
1 |
Clevis pin |
|
004 |
N/A
|
Not available |
1 |
Rear brush shaft weldment |
|
005 |
999-0507
|
Bolt M6-1 x 16mm hex head full thread plain finish |
2 |
|
|
006 |
999-0123
|
Washer 1/4 SAE flat zinc plated |
2 |
|
|
007 |
275-2017
|
BEARING, PILLOWBLOCK, 1.02B [SOLID PYE] (Tennant Industrial |
2 |
|
|
008 |
999-0309
|
Bolt M8-1.25 x 50mm hex head part thread zinc |
4 |
|
|
009 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
4 |
|
|
010 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
4 |
|
|
011 |
275-2028
|
ROD, THRD, FULL, .38-24 03.2L (Tennant Industrial) |
2 |
|
|
012 |
175-1431
|
Flexible pad driver assembly (OBSOLETE) |
4 |
|
|
013 |
999-0143
|
Nut 3/8-24 hex plain finish |
2 |
|
|
014 |
275-2753
|
PIN, CLEVIS, 0.38D X 1.13L (Tennant Industrial) |
4 |
|
|
015 |
N/A
|
Not available |
2 |
Extension spring |
|
016 |
N/A
|
Not available |
2 |
Clevis pin |
|
