| # | Part | Description |
Req | Notes | Availability |
|---|
001 |
175-0619
|
SPROCKET WLDT, #40, 96TOOTH, 7.00B (Tennant Industrial) |
1 |
|
|
002 |
175-0621
|
PIN, ROLL, .312D X 0.75L, .312/.318 (Tennant Industrial) |
4 |
|
|
003 |
175-0620
|
BLOCK, CLIP, SPRKT, .5 0.8W 01.0L (Tennant Industrial) |
4 |
|
|
004 |
999-9097
|
Washer M8 flat stainless steel |
1 |
|
|
005 |
275-1999
|
STEERING KIT, CHAIN (Tennant Industrial) (OBSOLETE) |
1 |
Includes 006 |
|
006 |
175-0583
|
LINK, CHAIN, RLR, 40 (Tennant Industrial) |
1 |
|
|
007 |
275-2000
|
PLATE, MTG, IDLER (Tennant Industrial) (OBSOLETE) |
1 |
|
|
008 |
N/A
|
Not available |
1 |
Includes 009 |
|
009 |
175-0589
|
BUSHING, FLNG, 0.71B 0.79D 0.47L, NYL (Tennant Industrial) |
2 |
|
|
010 |
N/A
|
Not available |
1 |
Steering housing |
|
011 |
N/A
|
Not available |
1 |
Lower steering shaft |
|
012 |
175-3198
|
Woodruff key |
1 |
|
|
013 |
175-9072
|
Ball bearing |
2 |
|
|
014 |
275-2003
|
Retaining ring (Tennant Industrial) |
2 |
|
|
015 |
N/A
|
Not available |
1 |
SPROCKET, 40, 10TOOTH, TLB (Tennant Industrial)
|
|
016 |
N/A
|
Not available |
1 |
Double u joint |
|
017 |
N/A
|
Not available |
1 |
Set screw |
|
018 |
275-1737
|
PIN, ROLL, .187D X 1.25L, .187/.192 (Tennant Industrial) |
1 |
|
|
019 |
175-0576
|
BUSHING, FLNG, 0.75B 1.00D 1.00L, NYL (Tennant Industrial) |
2 |
|
|
020 |
N/A
|
Not available |
1 |
BRACKET WLDT, MTG, CABLE, SOLTN CNTRL (Tennant Industrial)
|
|
021 |
175-2099
|
Flanged bushing |
2 |
|
|
022 |
N/A
|
Not available |
1 |
HANDLE WLDT, CNTRL, SOLTN (Tennant Industrial)
|
|
023 |
175-0687
|
KNOB, BALL, 1.38D 0.50-20, PLSTC (Tennant Industrial) |
1 |
|
|
024 |
N/A
|
Not available |
1 |
Steering column weldment |
|
025 |
N/A
|
Not available |
1 |
Upper steering shaft |
|
026 |
N/A
|
Not available |
1 |
Steering wheel |
|
027 |
N/A
|
Not available |
1 |
Steering wheel cap |
|
