| # | Part | Description |
Req | Notes | Availability |
|---|
0 |
175-9765
|
Charger 36VDC 30A 245VAC 1Ph 50Hz |
1 |
(includes 1-14) |
|
1 |
275-0226
|
Battery charger ammeter gauge |
1 |
|
|
2 |
275-0227
|
Battery charger fuse |
1 |
|
|
3 |
275-0222
|
Battery charger fuse holder |
1 |
|
|
4 |
275-4687
|
Capacitor |
1 |
|
|
5 |
275-0229
|
Battery charger circuit breaker |
1 |
|
|
6 |
275-0218
|
Battery charger control |
1 |
|
|
7 |
275-0221
|
Transformer control |
1 |
|
|
8 |
275-0210
|
Battery charger varistor |
1 |
|
|
9 |
275-0231
|
Battery charger diode |
2 |
|
|
10 |
991-2105
|
SB50 50amp charger plug with pins (gray) |
1 |
|
|
11 |
275-0223
|
120VAC wire with plug |
1 |
|
|
12 |
275-0209
|
Battery charger wire strain relief |
1 |
|
|
13 |
275-0232
|
36VDC wire with connector |
1 |
|
|
14 |
275-0208
|
Battery charger wire strain relief |
2 |
|
|
