| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
999-1383
|
Screw M6-1 x 16mm hex head stainless steel |
4 |
|
|
2 |
375-1520
|
Detergent holder plate |
1 |
|
|
3 |
275-9935
|
ec-H20 module (OBSOLETE) |
1 |
(includes 4-5) |
|
4 |
175-6347
|
Hose 1/4 inch x 13 foot |
1 |
|
|
5 |
275-4955
|
PVC hose |
1 |
|
|
6 |
999-0784
|
Screw M8-1.25 x 16mm hex head stainless steel |
2 |
|
|
7 |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
2 |
|
|
8 |
275-7249
|
Water module cover |
1 |
|
|
9 |
999-0016
|
Washer 1/4 flat plain finish |
1 |
|
|
10 |
999-1257
|
Screw M6-1 x 16mm pan head Phillips |
1 |
|
|
