| # | Part | Description |
Req | Notes | Availability |
|---|
000 |
275-4062
|
MOTOR, HYD, GEAR, INT 02.8 BI-DIR 1500 (Tennant Industrial) |
1 |
|
|
001 |
175-8249
|
Screw |
4 |
|
|
002 |
175-8243
|
VR, FLANGE, MOTOR, HYD [EN] (Tennant Industrial) |
1 |
|
|
003 |
175-8246
|
Thrust race |
1 |
|
|
004 |
175-8245
|
Bearing thrust |
1 |
|
|
005 |
275-1189
|
CLAMP, HOSE, WIR, .29 - .31 [DBL WIRE] (Tennant Industrial) |
1 |
|
|
006 |
175-8250
|
VR, HOUSING, MOTOR, HYD [EN] (Tennant Industrial) |
1 |
|
|
007 |
275-0938
|
Drive |
1 |
|
|
008 |
175-8251
|
Spacer plate (Tennant Industrial) |
1 |
|
|
009 |
275-4063
|
VR, GEROTOR SET, MOTOR, HYD [EN] (Tennant Industrial) |
1 |
|
|
010 |
275-4064
|
VR, END CAP, MOTOR, HYD [EN] (Tennant Industrial) |
1 |
|
|
011 |
275-0942
|
Screw cap |
5 |
|
|
012 |
175-8232
|
O - Ring plug |
1 |
|
|
013 |
275-4065
|
FITTING, HYD, PLUG, OM20 (Tennant Industrial) |
2 |
|
|
014 |
175-6746
|
Woodruff key |
1 |
|
|
015 |
275-4066
|
NUT, HEX, SLTD, .75-16 (Tennant Industrial) |
1 |
|
|
016 |
275-4067
|
VR, SEAL KIT, MOTOR [CL] (Tennant Industrial) |
1 |
|
|
017 |
175-8254
|
VR, INSTR, MOTOR, HYD, REPAIR [EN] (Tennant Industrial) |
1 |
|
|
