| # | Part | Description |
Req | Notes | Availability |
|---|
000 |
275-3995
|
BRUSH KIT, SIDE [6500] (Tennant Industrial) (OBSOLETE) |
1 |
|
|
001 |
275-3978
|
BRACKET, SBDC (Tennant Industrial) |
1 |
|
|
002 |
275-3979
|
PLATE, SPACER (Tennant Industrial) |
2 |
|
|
003 |
175-3258
|
Bolt M10-1.5 x 35mm hex head |
2 |
|
|
004 |
175-0791
|
Nut M10 x 1.5 hex flange |
2 |
|
|
005 |
275-3980
|
COVER WLDT, BRUSH, SBDC (Tennant Industrial) |
1 |
|
|
006 |
275-3981
|
PIN, CLEVIS, 0.50D X 5.00L (Tennant Industrial) |
1 |
|
|
007 |
175-2117
|
Cotter pin |
1 |
|
|
008 |
275-3982
|
BUSHING, FLNG, 0.50B 0.62D 0.40L (Tennant Industrial) |
2 |
|
|
009 |
275-3983
|
SKIRT, NEO, .18, 10.00W 10.00L, 04/ HOLE (Tennant Industria |
2 |
|
|
010 |
275-3984
|
PLATE, RETAINER (Tennant Industrial) |
2 |
|
|
011 |
175-0536
|
Bolt M6-1 x 20mm hex head thread forming |
21 |
|
|
012 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
29 |
|
|
013 |
275-3985
|
SKIRT, NEO, .12, 05.88W 14.32L, 03/ HOLE (Tennant Industria |
1 |
|
|
014 |
275-3986
|
PLATE, RETAINER (Tennant Industrial) |
1 |
|
|
015 |
275-3987
|
SKIRT, NEO, .12, 09.50W 59.26L, 11/ SL (Tennant Industrial) |
1 |
|
|
016 |
275-3988
|
PLATE, RETAINER (Tennant Industrial) |
1 |
|
|
017 |
275-3989
|
SKIRT, NEO, .12, 17.00W 64.99L, 09/ HOLE (Tennant Industria |
1 |
|
|
018 |
275-3990
|
RETAINER, SKIRT, .12, 1.0W X 39.3L, BLK (Tennant Industrial |
1 |
|
|
019 |
275-3991
|
RETAINER, SKIRT, .12, 1.0W X 16.7L, BLK (Tennant Industrial |
1 |
|
|
020 |
275-3992
|
ANGLE, STOP (Tennant Industrial) |
1 |
|
|
021 |
999-1133
|
Bolt M8-1.25 x 20mm hex head full thread plain |
2 |
|
|
022 |
275-3993
|
SEAL, RBR, 0.06, BMPR, SBDC, RH (Tennant Industrial) |
1 |
|
|
023 |
275-3994
|
SEAL, RBR, BMPR, SBDC, LH (Tennant Industrial) |
1 |
|
|
024 |
999-0665
|
Nut M8-1.25 flange lock |
2 |
|
|
025 |
999-1087
|
Bolt M6-1 x 25mm hex head stainless steel |
3 |
|
|
026 |
999-0497
|
Nut M6-1 nylon insert lock stainless steel |
3 |
|
|
