| # | Part | Description | Price | Req | Notes | Availability |
|---|
1a |
275-9252
|
24V 1HP brush motor assembly |
$1,588.29
|
1 |
(includes 1b-2b) |
ships same day |
1b |
275-5907
|
Carbon brush replacement kit (pkg of 4) |
$12.98
|
1 |
|
usually ships 10-16 days |
2a |
275-5908
|
Brush motor leads |
$5.28
|
2 |
|
usually ships 10-16 days |
2b |
275-5909
|
Terminal clip |
$5.28
|
1 |
|
usually ships 10-16 days |
3a |
275-1468
|
Square keyway |
$5.28
|
1 |
(between SN 10635450-40000000 and SN 80008823-90000000) |
usually ships 10-16 days |
3b |
275-5910
|
Square keyway |
$5.50
|
1 |
(before SN 10635451 and between SN 80000000-80008822) |
usually ships 10-16 days |
4 |
999-0777
|
Screw M4-.7 x 10mm hex head plain finish |
$0.99
|
1 |
|
ships same day |
5 |
999-1083
|
Washer #8 internal star lock stainless steel |
$0.99
|
1 |
|
ships same day |
6 |
175-5797
|
Washer 1/6 flat zinc |
$4.49
|
1 |
|
usually ships 10-16 days |
7 |
175-3671
|
Hose clamp |
$5.28
|
1 |
|
usually ships 10-16 days |
8 |
175-7913
|
Solution tube |
$163.57
|
1 |
|
usually ships 10-16 days |
9a |
275-9257
|
17 inch (430mm) brush housing |
$229.46
|
1 |
|
usually ships 1-5 days |
9b |
275-5916
|
20 inch(500mm) brush housing |
$447.48
|
1 |
|
usually ships 10-16 days |
10a |
175-7923
|
17 inch (430mm) bumper with bristle skirt |
$86.24
|
1 |
|
usually ships 10-16 days |
10b |
175-7916
|
20 inch (500mm) bumper with bristle skirt |
$154.99
|
1 |
|
ships same day |
11a |
275-1469
|
Shaft spacer |
$8.91
|
1 |
(between SN 10635450-40000000 and SN 80008823-90000000) |
usually ships 10-16 days |
11b |
175-1437
|
Spacer |
$10.45
|
2 |
(before SN 10635451 and between SN 80000000-80008822) |
ships same day |
12 |
999-1225
|
Screw M5-.8 x 12mm pan head phillips zinc |
$0.99
|
2 |
|
ships same day |
13 |
999-1026
|
Washer #10 internal lock stainless steel |
$0.99
|
2 |
|
ships same day |
14 |
999-0998
|
Washer #10 flat stainless steel |
$0.99
|
2 |
|
ships same day |
15 |
175-7921
|
Brush plate clamp |
$22.77
|
1 |
|
usually ships 10-16 days |
16 |
175-7924
|
Spring clip |
$7.37
|
1 |
|
usually ships 10-16 days |
17a |
275-9256
|
Drive hub |
$258.94
|
1 |
(between SN 10635450-40000000 and SN 80008823-90000000) |
ships same day |
17b |
675-9920
|
Drive hub |
$250.69
|
1 |
(before SN 10635451 and between SN 80000000-80008822) |
usually ships 1-5 days |
18a |
175-7920
|
Washer M8 flat stainless steel |
$4.49
|
1 |
(between SN 10635450-40000000 and SN 80008823-90000000) |
ships same day |
18b |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
$0.99
|
1 |
(before SN 10635451 and between SN 80000000-80008822) |
ships same day |
19 |
999-0553
|
Washer 5/16 medium split lock stainless steel |
$0.99
|
1 |
(before SN 10635451 and between SN 80000000-80008822) |
ships same day |
20a |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
$1.85
|
1 |
(between SN 10635450-40000000 and SN 80008823-90000000) |
ships same day |
20b |
999-0688
|
Bolt 5/16-18 x 1 1/4 hex head stainless steel |
$0.99
|
1 |
(before SN 10635451 and between SN 80000000-80008822) |
ships same day |
21 |
175-7917
|
Water containment ring |
$10.01
|
1 |
|
ships same day |
22 |
999-0562
|
Bolt 3/8-16 x 1 hex head stainless steel |
$1.50
|
4 |
(17 inch before SN 10635451) (20 inch before SN 10636750 and between SN 80000000-80008822) |
ships same day |
23 |
175-4494
|
Washer M10 |
$4.49
|
4 |
(17 inch between SN 10635450-40000000) (20 inch before SN 10636750 and between SN 80000000-80008822) |
usually ships 10-16 days |
24 |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
$0.99
|
4 |
(17 inch before SN 10635451) (20 inch before SN 10636750 and between SN 80000000-80008822) |
ships same day |
25 |
275-5913
|
Pin |
$28.93
|
1 |
|
usually ships 10-16 days |
26 |
175-4701
|
Pin head |
$21.23
|
1 |
|
usually ships 10-16 days |
27 |
175-1238
|
Moving parts decal |
$5.83
|
1 |
|
usually ships 10-16 days |
28 |
999-0770
|
Screw M8-1.25 x 30mm flat head socket stainless steel |
$2.62
|
1 |
|
ships same day |
29 |
175-7919
|
Guide wheel |
$5.50
|
1 |
|
ships same day |
30 |
175-2249
|
Sleeve |
$4.22
|
1 |
|
ships same day |
31 |
999-0024
|
Washer 5/16 flat stainless steel |
$1.34
|
1 |
|
usually ships 12-18 days |
32 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
$1.34
|
1 |
|
ships same day |
33 |
175-3718
|
Knob |
$5.28
|
1 |
|
ships same day |
34 |
275-5914
|
Compression spring |
$10.34
|
1 |
|
usually ships 10-16 days |
35 |
275-5915
|
Nut M14 x 2mm hex head stainless steel |
$5.28
|
1 |
|
usually ships 10-16 days |
36 |
275-4736
|
Screw M8-1.25 x 20mm hex washer head stainless steel SEMS |
$4.49
|
4 |
(between SN 10635450-40000000 and SN 80008823-90000000) |
usually ships 10-16 days |
