| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
275-1535
|
Pump mounting bracket |
1 |
|
|
2 |
999-1383
|
Screw M6-1 x 16mm hex head stainless steel |
10 |
|
|
3 |
997-2009
|
Hose clamp |
2 |
|
|
4 |
275-4752
|
Capacitor plug |
1 |
(after SN 10378379) |
|
5 |
175-7795
|
Cable tie |
2 |
(after SN 10378379) |
|
6 |
375-0291
|
Hose clamp |
11 |
|
|
7a |
275-1454
|
12 inch vinyl hose |
1 |
(OEM) (after SN 10378379) |
|
7b |
991-1405
|
Vinyl tubing 1/2 x 3/4 (sold by the inch) |
10 in |
(NON-OEM) |
|
8 |
175-3685
|
90 degree elbow fitting |
1 |
|
|
9 |
175-5869
|
Tee fitting 3/8 x 3/8 inch |
1 |
|
|
10 |
175-6863
|
Straight brass fitting |
1 |
|
|
11 |
175-7941
|
Air vent valve |
1 |
|
|
12 |
175-6081
|
Hose clamp |
2 |
|
|
13 |
175-7933
|
90 degree plastic elbow |
1 |
|
|
14a |
275-4753
|
24V solution pump |
1 |
(includes 14b-14f) (after SN 10378379) |
|
14b |
275-4754
|
Solution head pump kit |
1 |
(after SN 10378379) |
|
14c |
175-8753
|
Female connector |
1 |
|
|
14d |
175-8755
|
TERMINAL, FEM, MP280, SEALED, 18-16GA (Tennant Industrial) |
1 |
|
|
14e |
175-8754
|
14/16 wire seal |
1 |
|
|
14f |
175-8756
|
Male and female secondary lock |
1 |
|
|
15 |
275-4755
|
Tee fitting |
2 |
(after SN 10378379) |
|
16 |
175-6347
|
Hose 1/4 inch x 13 foot |
2 |
(after SN 10378379) |
|
17 |
175-1656
|
Hose clamp |
9 |
(after SN 10378379) |
|
18 |
175-1928
|
Plastic tee fitting |
1 |
(after SN 10378379) |
|
19 |
275-4756
|
Check valve |
1 |
(after SN 10378379) |
|
20 |
175-7303
|
1/4 inch union tee |
1 |
(after SN 10378379) |
|
21 |
275-4757
|
Fitting assembly |
1 |
(after SN 10378379) |
|
22 |
275-1796
|
Straight plastic fitting (Tennant Industrial) |
2 |
(after SN 10378379) |
|
23 |
275-1534
|
3 foot PVC hose (braided) (Tennant Industrial) |
1 |
(after SN 10378379) |
|
24 |
275-4758
|
Plastic tee fitting |
1 |
(after SN 10378379) |
|
25 |
275-8062
|
Horn |
1 |
(after SN 10378379) |
|
26 |
275-4759
|
Horn mounting bracket |
1 |
(after SN 10378379) |
|
27 |
999-0355
|
Washer 3/8 x 7/8 SAE flat stainless steel |
1 |
(after SN 10378379) |
|
28 |
999-0633
|
Bolt 1/4-20 x 5/8 hex head stainless steel |
1 |
(after SN 10378379) |
|
29 |
275-4760
|
Press switch |
1 |
(after SN 10378379) |
|
30 |
175-3529
|
Brass fitting |
1 |
(after SN 10378379) |
|
31 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
1 |
(after SN 10378379) |
|
32 |
175-3176
|
Washer 3/8 flat steel plated |
1 |
(after SN 10378379) |
|
33 |
175-2260
|
P clamp |
1 |
(after SN 10378379) |
|
34 |
275-1537
|
45 inch vinyl tubing |
1 |
|
|
35a |
275-1454
|
12 inch vinyl hose |
2 |
(OEM) |
|
35b |
991-1405
|
Vinyl tubing 1/2 x 3/4 (sold by the inch) |
10 in |
(NON-OEM) |
|
36 |
175-5304
|
Hose clamp |
1 |
(after SN 10378379) |
|
37 |
275-1523
|
90 degree brass elbow |
1 |
|
|
38 |
275-4748
|
Martini mounting bracket |
1 |
(after SN 10378379) |
|
39 |
275-9935
|
ec-H20 module (OBSOLETE) |
1 |
(includes 16 and 40) (after SN 10448304) |
|
40 |
275-4750
|
64 inch hose |
1 |
(after SN 10378379) |
|
41 |
175-3329
|
Plastic tee fitting |
1 |
|
|
42 |
175-7834
|
Plastic fitting |
1 |
|
|
43 |
175-1043
|
3 inch hose |
1 |
|
|
44 |
175-1025
|
Straight brass fitting |
2 |
|
|
45 |
175-3690
|
U clamp |
2 |
|
|
46 |
999-0998
|
Washer #10 flat stainless steel |
4 |
|
|
47 |
999-0740
|
Nut M5-.8 hex stainless steel |
4 |
|
|
48a |
175-9025
|
In-line screen filter assembly |
1 |
(includes 49-52) (OEM) |
|
48b |
991-8582
|
Mesh inline filter |
1 |
(NON-OEM) |
|
49 |
175-5865
|
Top filter body housing |
1 |
|
|
50a |
175-5866
|
Mesh filter screen |
1 |
(OEM) |
|
50b |
991-8569
|
Mesh filter screen stainless steel |
1 |
(NON-OEM) |
|
51 |
175-5867
|
Filter gasket |
1 |
|
|
52a |
175-5868
|
Short clear filter bowl |
1 |
(OEM) |
|
52b |
991-8575
|
Short bowl (clear) |
1 |
(NON-OEM) |
|
53 |
175-2882
|
Filter mounting bracket weldment |
1 |
|
|
54 |
175-7930
|
Indicator valve knob (black) |
1 |
|
|
55 |
175-2884
|
Solution flow decal |
1 |
|
|
56 |
175-2883
|
Solution decal bracket |
1 |
|
|
57 |
175-7884
|
24V solution solenoid valve assembly |
1 |
(includes 58) |
|
58 |
175-8698
|
Solenoid valve rebuild kit (internal parts) |
1 |
|
|
