| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
175-8827
|
Foam gasket |
1 |
|
|
2 |
999-1161
|
Nut M3-.5 hex nylock stainless steel |
2 |
|
|
3 |
999-1158
|
Washer #6 flat stainless steel |
4 |
|
|
4 |
175-7836
|
Snap switch |
1 |
|
|
5 |
999-0740
|
Nut M5-.8 hex stainless steel |
2 |
|
|
6 |
999-0998
|
Washer #10 flat stainless steel |
2 |
|
|
7 |
275-1540
|
Squeegee spring lever with 90 degree bend |
1 |
|
|
8 |
999-0496
|
Nut M8-1.25 nylon insert lock stainless steel |
1 |
|
|
9 |
275-7133
|
Washer .34B x 1.25D x .11 flat stainless steel |
1 |
|
|
10 |
275-1541
|
Squeegee lift bracket |
1 |
|
|
11 |
999-1383
|
Screw M6-1 x 16mm hex head stainless steel |
2 |
|
|
12 |
175-2748
|
Spring |
1 |
|
|
13 |
175-7813
|
Knob |
1 |
|
|
14 |
275-1542
|
Squeegee lever |
1 |
|
|
15 |
175-7860
|
Ball joint |
2 |
|
|
16 |
999-1308
|
Nut M6-1 hex stainless steel |
2 |
|
|
17 |
275-1543
|
Squeegee lift cable |
1 |
|
|
18 |
999-0497
|
Nut M6-1 nylon insert lock stainless steel |
2 |
|
|
19 |
175-7856
|
Washer M13-.8 x 30mm flat nylon |
2 |
|
|
20 |
175-2249
|
Sleeve |
1 |
|
|
21 |
999-1040
|
Screw M3-.5 x 20mm pan head |
2 |
|
|
22 |
175-8735
|
Cable bushing |
1 |
|
|
23 |
175-3008
|
Retaining ring |
1 |
|
|
24 |
999-6696
|
Bolt M12-1.75 x 30mm stainless steel hex cap screw |
2 |
(after SN 10387969) |
|
25 |
999-0519
|
Nut M12-1.75 nylon insert lock stainless steel |
2 |
(after SN 10387969) |
|
26 |
999-0559
|
Washer 1/2 x 1/4 flat stainless steel |
5 |
|
|
27 |
175-7890
|
Sleeved bushing |
2 |
|
|
28 |
275-1544
|
Squeegee pivot weldment bracket |
1 |
|
|
29 |
275-1545
|
Squeegee bracket replacement kit |
1 |
(after SN 10387969 - T5) |
|
30 |
175-8740
|
Flanged bearing |
2 |
|
|
31 |
275-4777
|
Clevis pin |
1 |
|
|
32 |
175-4331
|
Cotter hair pin |
1 |
|
|
33 |
275-1545
|
Squeegee bracket replacement kit |
1 |
(before SN 10387970 - T5) |
|
34 |
999-0126
|
Washer 1/2 split lock |
2 |
(before SN 10387970) |
|
35 |
275-1547
|
Screw M12 x 1 3/4 x 25 hex stainless steel |
2 |
(before SN 10387970) |
|
