| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-2926
|
Vacuum handle assembly |
1 |
(includes 2-5) |
|
2 |
375-2927
|
Handle halves with hardware |
1 |
(includes 7 screws) |
|
3 |
375-2928
|
3 position switch |
1 |
|
|
4 |
375-2929
|
Handle harness |
1 |
|
|
5 |
375-2930
|
Handle tube |
1 |
|
|
6 |
375-2931
|
Handle braket assembly |
1 |
(includes 3 screws) |
|
7 |
375-2932
|
Vacuum latch assembly |
1 |
|
|
8 |
375-2933
|
VACUUM BATTERY 44 VDC 2.9AH |
1 |
(includes 16) |
|
9 |
375-2934
|
Cable cover assembly |
1 |
(includes 4 screws) |
|
10 |
375-2935
|
120V 1.5amp battery charger |
1 |
|
|
11 |
375-2936
|
Handle duct assembly |
1 |
(includes 4 nuts and 6 screws) |
|
12 |
375-2937
|
Bag holder collar |
1 |
|
|
13 |
375-2938
|
Hard bag cover |
1 |
|
|
14 |
375-2939
|
HEPA bag filter |
1 |
|
|
15 |
375-1687
|
Vacuum charger cord |
1 |
|
|
16 |
375-2940
|
Warning label |
1 |
|
|
