| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-3204
|
Eccentric drive kit |
1 |
(includes 2-12) |
|
2 |
375-3199
|
Square key |
1 |
|
|
3 |
N/A
|
Not available |
1 |
(step balance) (only available with 1) |
|
4 |
N/A
|
Not available |
1 |
(eccentric spacer) (only available with 1) |
|
5 |
999-1383
|
Screw M6-1 x 16mm hex head stainless steel |
3 |
|
|
6 |
N/A
|
Not available |
1 |
(outer retainer plate) (only available with 1) |
|
7 |
375-3462
|
Ball bearing |
1 |
|
|
8 |
N/A
|
Not available |
1 |
(bearing housing) (only available with 1) |
|
9 |
N/A
|
Not available |
1 |
(bearing retainer) (only available with 1) |
|
10 |
999-1268
|
Screw M6-1 x 12mm socket head stainless steel |
2 |
|
|
11 |
375-3463
|
Seal |
1 |
|
|
12 |
375-0288
|
Screw M6-1 x 35mm flat socket |
6 |
|
|
