| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-2477
|
Inlet valve (OBSOLETE) |
4 |
|
|
2 |
375-2478
|
Exhaust valve (OBSOLETE) |
4 |
|
|
3 |
575-0898
|
VR, SPRING (Tennant Industrial) |
8 |
|
|
4 |
575-3301
|
VR, RETAINER (Tennant Industrial) |
8 |
|
|
5 |
575-2382
|
VR, COLLET, SPRING, VALVE (Tennant Industrial) |
8 |
|
|
6 |
575-2355
|
VR, SEAL (Tennant Industrial) |
8 |
|
|
7 |
575-0788
|
VR, CAP, VALVE (Tennant Industrial) |
8 |
|
|
8 |
375-2479
|
Rocket arm shaft assembly (OBSOLETE) |
1 |
(includes 9) |
|
9 |
375-2480
|
Set screw (OBSOLETE) |
2 |
|
|
10 |
575-6486
|
VR, BRACKET (Tennant Industrial) |
4 |
|
|
11 |
575-0208
|
VR, STUD (Tennant Industrial) |
4 |
|
|
12 |
275-3839
|
VR, NUT (Tennant Industrial) |
4 |
|
|
13 |
175-8507
|
VR, WASHER, LOCK, SPLIT [KU,04512-50080] (Tennant Industria |
4 |
|
|
14 |
175-8496
|
VR, WASHER, FLAT [KU] (Tennant Industrial) |
4 |
|
|
15 |
375-2481
|
Set screw (OBSOLETE) |
1 |
|
|
16 |
375-2482
|
Washer (OBSOLETE) |
2 |
|
|
17 |
375-2483
|
Rocker arm spring (OBSOLETE) |
3 |
|
|
18 |
375-2484
|
External cir-clip (OBSOLETE) |
2 |
|
|
19 |
375-2485
|
Rocker arm (OBSOLETE) |
8 |
|
|
20 |
375-2486
|
Adjusting screw (OBSOLETE) |
8 |
|
|
21 |
375-2487
|
Nut (OBSOLETE) |
8 |
|
|
