| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-2470
|
Water flange (OBSOLETE) |
1 |
(includes 2) |
|
2 |
N/A
|
Not available |
1 |
(water return pipe) |
|
3 |
375-2471
|
Water flange gasket (OBSOLETE) |
1 |
|
|
4 |
275-3843
|
VR, BOLT (Tennant Industrial) |
2 |
|
|
5 |
475-9350
|
VR, STUD, EXHAUST [KU] (Tennant Industrial) |
1 |
|
|
6 |
475-9286
|
VR, BOLT, HEX [KU] (Tennant Industrial) |
1 |
|
|
7 |
275-3839
|
VR, NUT (Tennant Industrial) |
1 |
|
|
8 |
175-8507
|
VR, WASHER, LOCK, SPLIT [KU,04512-50080] (Tennant Industria |
2 |
|
|
9 |
575-2346
|
VR, PIPE, WATER (Tennant Industrial) |
1 |
|
|
10 |
375-2472
|
Pipe band (OBSOLETE) |
2 |
|
|
11 |
575-0170
|
VR, PLUG (Tennant Industrial) |
1 |
|
|
12 |
375-2473
|
Washer with rubber (OBSOLETE) |
1 |
|
|
13 |
675-0433
|
VR, HOUSING, THERMOSTAT [KU] (Tennant Industrial) |
1 |
|
|
14 |
575-1318
|
VR, GASKET (Tennant Industrial) |
1 |
|
|
15 |
275-3777
|
VR, BOLT [KU] (Tennant Industrial) |
2 |
|
|
16 |
675-0241
|
VR, THERMOSTAT, 180DEG, 1.7D [KU] (Tennant Industrial) |
1 |
|
|
