| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-1996
|
Shaft (OBSOLETE) |
1 |
|
|
2 |
575-9046
|
VR, GEAR, CAMSHAFT (Tennant Industrial) |
1 |
|
|
3 |
375-1997
|
Pin (OBSOLETE) |
1 |
|
|
4 |
375-1998
|
Washer |
1 |
|
|
5 |
999-1801
|
Screw M6 X 12mm hex head flange |
1 |
|
|
6 |
375-1999
|
Camshaft plate |
1 |
|
|
7 |
375-2000
|
Screw M6 with washer |
2 |
|
|
8 |
575-6366
|
VR, SEAL, OIL, CSHFT, FRONT [FD] (Tennant Industrial) |
1 |
|
|
9a |
375-1968
|
Rear bearing (OBSOLETE) |
1 |
(standard) |
|
9b |
375-1969
|
Rear bearing (OBSOLETE) |
1 |
|
|
10 |
375-1971
|
Front bearing (OBSOLETE) |
1 |
|
|
