| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-1955
|
Recovery tank with decals (OBSOLETE) |
1 |
|
|
2 |
175-2247
|
Plastic fitting |
1 |
|
|
3 |
175-3414
|
Tank cover |
1 |
|
|
4 |
175-3384
|
Tank cap |
3 |
(includes 5) |
|
5 |
175-3385
|
Lid gasket |
1 |
|
|
6 |
575-3795
|
BRACKET, MTG, TANK (Tennant Industrial) |
1 |
|
|
7 |
375-1956
|
Spacer shim (OBSOLETE) |
1 |
|
|
8 |
375-1954
|
Plastic fitting (OBSOLETE) |
2 |
|
|
9 |
675-5766
|
LEVEL SENSING ASSY (Tennant Industrial) |
1 |
(includes 10-13) |
|
10 |
575-2806
|
BELLOWS, RBR, 0.75ID 10.3L (Tennant Industrial) |
1 |
|
|
11 |
275-9876
|
Float (Tennant Industrial) (OBSOLETE) |
1 |
|
|
12 |
575-0795
|
PLUG, FLOAT, RND, NAT RESIN (Tennant Industrial) |
1 |
|
|
13 |
175-0337
|
Snap switch |
1 |
|
|
14 |
275-2281
|
GASKET, NEO, .12, 2.00ID, 5/2.8BC (Tennant Industrial) |
1 |
|
|
15 |
275-6396
|
Drain hose assembly (Tennant Industrial) |
1 |
|
|
16 |
175-3381
|
Plastic hose clamp 1.6 ID x .62 |
1 |
|
|
17 |
175-6741
|
PLUG, HOLE, RND, 1.00H .00-.17, BLK NYL (Tennant Industrial |
1 |
|
|
18 |
575-3128
|
BRACKET, ANGLE (Tennant Industrial) |
2 |
|
|
19 |
175-3386
|
Insert cover |
1 |
|
|
20 |
175-3387
|
Seal |
1 |
|
|
21 |
175-3388
|
Drain cap gasket |
1 |
|
|
22 |
175-3389
|
Lid gasket |
1 |
|
|
23 |
175-3390
|
Drain tank cap 3.85 thread pye |
1 |
|
|
24 |
175-3393
|
Cap gasket |
1 |
|
|
25 |
175-3394
|
Drain tank cap 2.25 thread pye |
1 |
|
|
26 |
175-3395
|
3/4 ID retaining extension ring stainless steel |
1 |
|
|
27 |
175-3392
|
Strap |
1 |
|
|
28 |
675-4597
|
COVER, TANK, CLEAN-OUT (Tennant Industrial) |
1 |
|
|
29 |
575-8175
|
SCREEN, INLET, VACFAN (Tennant Industrial) |
1 |
|
|
