| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
675-2038
|
LINK WLDT, SCB (Tennant Industrial) |
2 |
|
|
2 |
275-6956
|
Flange bearing |
8 |
|
|
3 |
475-9160
|
WASHER, FLAT, 0.75, STD (Tennant Industrial) |
4 |
|
|
4 |
575-6132
|
PIN, 0.75D 06.8L 1/.27H, 1CHAM (Tennant Industrial) |
4 |
|
|
5 |
675-6052
|
FRAME WLDT, MTG, BRUSH (Tennant Industrial) |
1 |
|
|
6 |
675-1409
|
BAR, PIVOT, ADJ, SCB BRUSH (Tennant Industrial) |
2 |
|
|
7 |
175-6917
|
Cylinder (Tennant Industrial) |
1 |
|
|
8 |
175-6919
|
Elbow fitting |
2 |
|
|
9 |
475-8321
|
RING, RETAINING, EXT, 0.50D, [SELFLOCK] (Tennant Industrial) |
2 |
|
|
10 |
575-2005
|
LEVER (Tennant Industrial) |
1 |
|
|
11 |
575-2663
|
LEVER (Tennant Industrial) |
1 |
|
|
12 |
575-0030
|
PIN, CLEVIS, 0.50D X 1.50L (Tennant Industrial) |
1 |
|
|
13 |
675-0148
|
CABLE, SS .12D 010.1L .3CLEVIS /.38EYE (Tennant Industrial) |
1 |
|
|
14 |
575-0744
|
PIN, CLEVIS, 0.25D X 0.75L (Tennant Industrial) |
1 |
|
|
15 |
575-8555
|
GASSPRING KIT, 34LB, F/31182, REPLMT (Tennant Industrial) |
1 |
(before SN010148) |
|
16 |
175-0761
|
Gas spring ball stud |
2 |
|
|
17 |
275-1876
|
CLIP, SAFETY, GASSPRING (Tennant Industrial) |
2 |
(before SN010148) |
|
18 |
675-0843
|
GASSPRING, 34LB, 6.3STRK (Tennant Industrial) |
1 |
(after SN 010147) |
|
