| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
375-1938
|
Lower pedal weldment (OBSOLETE) |
1 |
|
|
2 |
275-2975
|
PEDAL, PROPEL, UPPER (Tennant Industrial) |
1 |
|
|
3 |
275-2976
|
PIN, CLEVIS, 0.37D X 4.50L (Tennant Industrial) |
1 |
|
|
4 |
275-2977
|
PIN, COTTER, HAIR, 13MMD 3MM WIR (Tennant Industrial) |
1 |
|
|
5 |
175-5401
|
Clevis pin 1/2 x 4 1/2 |
1 |
|
|
6 |
175-3307
|
Non-skid tread |
2 |
|
|
7 |
173-1595
|
Clevis pin |
1 |
|
|
8 |
475-9788
|
BALLJOINT, #10-32 FEM, #10-32 MAL (Tennant Industrial) |
1 |
|
|
9 |
575-0799
|
BALLJOINT, #10-32 FEM, BODY & CLIP ONLY (Tennant Industrial) |
1 |
|
|
10 |
475-9212
|
STUD, BALL, .25D .10-32, BALLJOINT (Tennant Industrial) |
1 |
|
|
11 |
375-1939
|
Cam replacement kit (OBSOLETE) |
1 |
(before SN 010439) |
|
12 |
375-1940
|
Clevis pin (OBSOLETE) |
1 |
|
|
13 |
375-1941
|
2 hole conduit clamp (OBSOLETE) |
2 |
|
|
14 |
675-0032
|
CABLE, PUSH / PULL, 084.0L 10-32/10-32 (Tennant Industrial) |
1 |
|
|
15 |
275-2871
|
CLAMP, CABLE, STL, 0.38D X 0.62W, 1HOLE (Tennant Industrial |
1 |
|
|
16 |
575-7387
|
CAM, LIMITER, SPD (Tennant Industrial) |
1 |
(after SN 010438) |
|
17 |
999-0187
|
Washer 1/2 flat plain finish |
3 |
(after SN 010438) |
|
