| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
175-3168
|
P clamp |
1 |
|
|
2a |
375-1918
|
Tank cradle panel (OBSOLETE) |
1 |
(before SN 010372) |
|
2b |
575-8733
|
TRAY, DETGT (Tennant Industrial) |
1 |
(after SN 010371) |
|
3 |
375-0650
|
LPG tank strap (Tennant Industrial) |
1 |
|
|
4 |
375-0652
|
LPG tank strap (Tennant Industrial) |
1 |
|
|
5 |
375-0651
|
LPG tank strap (Tennant Industrial) |
1 |
|
|
6 |
154-0005
|
Propane tank strap |
1 |
(includes 7) |
|
7 |
275-0323
|
LPG tank mounting adjustment nut |
1 |
|
|
8 |
275-0324
|
LPG female quick disconnect brass fitting |
1 |
|
|
9a |
275-0325
|
HOSE, LPG, MED05, PM04STR/SM04STR, 027.0 (Tennant Industria |
1 |
(before SN 010372) |
|
9b |
575-7670
|
HOSE, LPG, MED05, PM04STR/SM04STR, 035.0 (Tennant Industrial |
1 |
(after SN 010371) |
|
10 |
575-2589
|
FITTING, HYD, TEE, PF04/PF04/PM04, RUN (Tennant Industrial) |
1 |
|
|
11 |
175-4814
|
Brass strainer fitting |
1 |
|
|
12 |
575-7714
|
BRACKET, MTG, VALVE, RELIEF (Tennant Industrial) |
1 |
|
|
13 |
175-2614
|
90 degree elbow fitting |
1 |
|
|
14 |
275-2890
|
FITTING, BRS, STR, PF04/PM04 (Tennant Industrial) |
1 |
|
|
15 |
275-0326
|
LPG pressure relief valve |
1 |
|
|
16 |
275-0328
|
HOSE, LPG, MED05, PM04STR/PM04STR, 043.0 (Tennant Industria |
1 |
|
|
17 |
175-2260
|
P clamp |
2 |
|
|
18a |
375-1919
|
Tank bracket assembly with decal (OBSOLETE) |
1 |
(before SN 010372) |
|
18b |
675-2663
|
BRACKET ASSY, TANK, LPG, W/ LABEL (Tennant Industrial) |
1 |
(after SN 010371) |
|
19 |
175-8119
|
LABEL, LOGO, 10.4L, WHITE [TENNANT] (Tennant Industrial) |
1 |
(before SN 010372) |
|
20 |
275-0330
|
45 degree elbow hydraulic fitting |
1 |
|
|
21 |
375-0648
|
LPG tank (Tennant Industrial) |
1 |
|
|
22 |
275-8203
|
Molding |
1 |
(before SN 010372) |
|
N/S |
675-1680
|
PANEL WLDT, CRADLE, TANK, LPG (Tennant Industrial) |
1 |
(after SN 010371) |
|
N/S |
575-3984
|
BRACKET, MTG, TANK, LPG (Tennant Industrial) |
1 |
(after SN 010371) |
|
