| # | Part | Description |
Req | Notes | Availability |
|---|
1a |
675-4599
|
DOOR WLDT, BRUSH, LH (Tennant Industrial) |
1 |
|
|
1b |
675-5042
|
DOOR WLDT, BRUSH, RH (Tennant Industrial) |
1 |
|
|
2 |
575-0532
|
SEAL, RBR, OPEN, 0.31, 0.75W 21.0L ADH (Tennant Industrial) |
1 |
|
|
3 |
575-7565
|
HINGE, .38PIN .11 3.5W 05.6L, 4/H&S (Tennant Industrial) |
1 |
|
|
4a |
575-8169
|
LATCH (Tennant Industrial) |
1 |
(left hand) |
|
4b |
275-7456
|
LATCH (Tennant Industrial) |
1 |
(right hand) |
|
5 |
275-6024
|
LATCH, BOLT (Tennant Industrial) |
1 |
|
|
6a |
275-7378
|
SKIRT ASSY, DOOR, MAIN BRUSH, LH (Tennant Industrial) |
1 |
|
|
6b |
275-7379
|
SKIRT ASSY, DOOR, MAIN BRUSH, RH (Tennant Industrial) |
1 |
|
|
7a |
375-2107
|
Left hand door hinge bracket kit (OBSOLETE) |
1 |
|
|
7b |
575-5972
|
BRACKET KIT, HINGE, DOOR, RH, CI [6600] (Tennant Industrial) |
1 |
|
|
8 |
575-7472
|
RETAINER, SKIRT, .12, 1.5W X 17.5L, BLK (Tennant Industrial) |
1 |
|
|
9a |
375-1221
|
Brush seal ( Tennant Industrial) |
1 |
(left hand) |
|
9b |
375-1225
|
Brush seal (Tennant Industrial) |
1 |
(right hand) |
|
10 |
575-3862
|
STRAP (Tennant Industrial) |
1 |
|
|
11 |
575-9135
|
SKIRT, DEFLECTOR, NEO, .12 (Tennant Industrial) |
2 |
|
|
12 |
575-5827
|
STRAP (Tennant Industrial) |
2 |
|
|
13 |
675-1901
|
BRACKET, ANGLE, .12 2.75W 3.2 1.0L (Tennant Industrial) |
2 |
|
|
14 |
175-3378
|
Rivet 1/4 x 57/64 plastic |
5 |
|
|
