| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
175-9035
|
Knob |
1 |
(Serial number 10000000-10517541, and 50000000-50000251) |
|
2a |
175-5222
|
Attention users decal (FaST) |
1 |
|
|
2b |
275-5732
|
Attention users decal (ec-H2O) |
1 |
|
|
3 |
175-4220
|
Solution fill screen assembly |
1 |
(Serial number 10000000-10517541, and 50000000-50000251) |
|
4 |
175-4220
|
Solution fill screen assembly |
1 |
(Serial number 10000000-10517541, and 50000000-50000251) |
|
5 |
999-1111
|
Screw 6-32 x 3/4 pan head phillips sheet metal |
2 |
|
|
6 |
999-1158
|
Washer #6 flat stainless steel |
2 |
|
|
7 |
175-4220
|
Solution fill screen assembly |
1 |
(Serial number 10000000-10517541, and 50000000-50000251) |
|
8 |
175-5129
|
Ball chain #10 stainless steel |
1 |
(Serial number 10000000-10517541, and 50000000-50000251) |
|
9 |
999-0531
|
Screw M5-.8 x 16mm pan head slotted zinc |
2 |
(Serial number 10000000-10517541, and 50000000-50000251) |
|
10 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
3 |
|
|
11 |
999-1026
|
Washer #10 internal lock stainless steel |
1 |
(Serial number 10000000-10517541, and 50000000-50000251) |
|
12 |
999-0726
|
Screw 10-32 x 5/8 pan head phillips zinc plated |
1 |
(Serial number 10000000-10517541, and 50000000-50000251) |
|
13 |
175-3370
|
Screw M4-.7 x 8mm pan head stainless steel |
2 |
|
|
14 |
999-1083
|
Washer #8 internal star lock stainless steel |
2 |
|
|
15a |
175-3369
|
Hood latch |
1 |
(OEM) |
|
15b |
991-8561
|
Rubber draw latch with keeper |
1 |
(NON-OEM) |
|
16 |
175-4629
|
P clamp |
3 |
|
|
17 |
999-1383
|
Screw M6-1 x 16mm hex head stainless steel |
5 |
|
|
18a |
375-1287
|
T5e side label |
2 |
(all serial numbers) |
|
18b |
N/A
|
Not available |
2 |
(Serial number 10000000-20000000, and 50000000-60000000) |
|
19 |
175-9240
|
Screw M8-1.25 x 25mm flat head socket nylok stainless steel |
1 |
|
|
20 |
175-2876
|
Tank guide spacer |
1 |
|
|
21 |
175-2651
|
Support cable |
1 |
|
|
22 |
375-1288
|
T5e solution tank kit |
1 |
|
|
23 |
275-1404
|
Charger setting instruction decal |
1 |
|
|
24 |
175-7825
|
Solution fill port cap |
1 |
|
|
25 |
175-2254
|
Hose clamp |
1 |
|
|
26 |
275-5086
|
Plastic fitting |
1 |
|
|
27a |
275-1388
|
Solution tank drain hose |
1 |
(OEM) |
|
27b |
991-3075
|
Solution drain hose |
1 |
(NON-OEM) |
|
28 |
175-2878
|
Nut 3/8-32 hex switch boot |
1 |
|
|
29 |
175-3689
|
Screw M5-.8 x 12mm truss head phillips stainless steel |
2 |
|
|
30 |
175-2879
|
Cable stay hose bracket |
1 |
|
|
31a |
175-0084
|
Actuator push switch |
1 |
(OEM) |
|
31b |
991-8558
|
Switch |
1 |
(NON-OEM) |
|
32 |
275-5295
|
ec-H2O decal (teal) |
2 |
(Serial number 10378380-20000000, and 50000000-60000000) |
|
33 |
275-5293
|
ec-H20 decal (teal) |
1 |
(Serial number 10378380-20000000, and 50000000-60000000) |
|
34 |
175-4220
|
Solution fill screen assembly |
1 |
(Serial number 10517542-20000000, and 50000252-60000000) |
|
