| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
275-3319
|
Switch |
1 |
|
|
2 |
175-9416
|
Power bag |
1 |
|
|
3 |
175-3378
|
Rivet 1/4 x 57/64 plastic |
2 |
|
|
4 |
275-3939
|
CLIP, GRIP, FINGER, 1.00-1.88D,WHITE VYL (Tennant Industria |
1 |
|
|
5 |
175-3291
|
SCREW, HEX, M4 X 0.70 X 20, 8.8 (Tennant Industrial) |
1 |
|
|
6 |
999-0377
|
Washer 6 SAE flat plain finish |
2 |
|
|
7 |
999-0954
|
Nut M4-.7 nylon insert lock stainless steel |
1 |
|
|
8a |
275-8716
|
TRAY WLDT, POWER WAND (Tennant Industrial) |
1 |
(before SN 005000) |
|
8b |
275-2614
|
Power wand tray weldment (gray) (Tennant Industrial) |
1 |
(after SN 004999) |
|
9 |
999-0499
|
Bolt M8-1.25 x 20mm hex head full thread stainless steel |
3 |
|
|
10a |
275-8718
|
HARNESS, WAND, POWER [7300/8300] (Tennant Industrial) |
1 |
(after SN 001705) |
|
10b |
275-8717
|
HARNESS, WAND, POWER [7300/8300] (Tennant Industrial) |
1 |
(before SN 001706) |
|
11 |
175-2162
|
Nylon wire tie |
4 |
(before SN 001706) |
|
12 |
999-0355
|
175-2249 |
3 |
|
|
