| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
175-3140
|
Battery tray |
1 |
|
|
2 |
162-0057
|
12V 150Ah wet battery |
2 |
|
|
3 |
175-3137
|
Battery cable (black) |
1 |
|
|
4 |
175-3138
|
Battery cable 5/16 x 3/8 (red) |
1 |
|
|
5 |
998-0010
|
Battery jumper cable - ring type (red) |
1 |
|
|
6 |
175-1103
|
Battery cable boot (black) |
4 |
|
|
7 |
175-3139
|
24V 19amp off board battery charger |
1 |
(includes 8) |
|
8 |
991-9284
|
50amp charger plug SB50 with pins (red) |
1 |
|
|
9 |
275-0052
|
16/3 charger extension cord 10 foot |
1 |
|
|
