| # | Part | Description |
Req | Notes | Availability |
|---|
001a |
275-0010
|
OHG KIT, CI [7200 R/O] (Tennant Industrial) (OBSOLETE) |
1 |
|
|
001b |
175-9653
|
Overhead guard rear leg tube weldment |
2 |
|
|
002 |
275-0011
|
GUARD, OVERHEAD, TOP, R/O (Tennant Industrial) (OBSOLETE) |
1 |
|
|
003 |
999-9092
|
Screw M8-1.25 x 20mm hex head stainless steel |
2 |
|
|
004 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
3 |
|
|
005 |
175-9655
|
Screw 12-1.75 x 80 hex head stainless steel |
4 |
|
|
006 |
999-0114
|
Washer 1/2 SAE flat |
16 |
|
|
007 |
999-0519
|
Nut M12-1.75 nylon insert lock stainless steel |
8 |
|
|
008 |
175-9656
|
Screw 12-1.75 x 40 hex head stainless steel |
4 |
|
|
009 |
999-0471
|
Nut M8-1.25 nylon insert lock zinc plated |
1 |
|
|
