| # | Part | Description |
Req | Notes | Availability |
|---|
001a |
175-9645
|
36 volt overhead guard revolving light kit (Tennant Industri |
1 |
|
|
001b |
375-4398
|
LED strobe light (Tennant Industrial) |
1 |
|
|
001c |
275-4675
|
Lens |
1 |
|
|
001d |
275-4676
|
Bulb |
1 |
|
|
001e |
175-5964
|
Plug |
2 |
|
|
002 |
175-9646
|
Light mounting plate |
1 |
|
|
003 |
175-9647
|
Overhead guard light mounting bracket |
1 |
|
|
004 |
175-5419
|
Grommet 5/8 |
1 |
|
|
005 |
175-0837
|
Bolt M5-.8 x 16mm hex head |
2 |
|
|
006 |
999-0006
|
Washer 3/16 flat zinc plated |
2 |
|
|
007 |
175-2894
|
Nut M5-.8 hex nylon locking |
2 |
|
|
008 |
175-3261
|
PVC duct |
1 |
|
|
009 |
175-9650
|
Vinyl duct 25/64 x 3/4 x 1/4d 26l (OBSOLETE) |
1 |
|
|
010 |
999-0507
|
Bolt M6-1 x 16mm hex head full thread plain finish |
2 |
|
|
011 |
999-0016
|
Washer 1/4 flat plain finish |
2 |
|
|
012 |
999-6694
|
Nut M6-1 hex serrated flange stainless steel |
2 |
|
|
013 |
175-9648
|
Revolving or flashing light harness |
1 |
|
|
014 |
175-3233
|
Cable tie mount |
2 |
|
|
015 |
175-2162
|
Nylon wire tie |
2 |
|
|
016a |
175-9640
|
36 volt revolving light assembly |
1 |
|
|
016b |
175-5418
|
Revolving light amber lens |
1 |
|
|
016c |
175-5417
|
Lamp |
1 |
|
|
016d |
175-5422
|
Revolving light red lens |
1 |
|
|
016e |
175-5423
|
Revolving light blue lens |
1 |
|
|
