| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
275-7077
|
Electrical component panel |
$43.78
|
1 |
|
usually ships 1-5 days |
2 |
999-1383
|
Screw M6-1 x 16mm hex head stainless steel |
$3.96
|
4 |
|
ships same day |
3 |
275-7078
|
200amp shunt |
$123.42
|
1 |
|
usually ships 1-5 days |
4 |
999-9113
|
Screw M4-.7 x 16mm pan head phillips stainless steel |
$0.99
|
2 |
|
ships same day |
5 |
175-3226
|
Insulated stand off |
$9.57
|
1 |
|
ships same day |
6 |
175-3227
|
Threaded rod |
$7.59
|
1 |
|
usually ships 1-5 days |
7 |
175-4544
|
Washer M6 locking |
$4.09
|
2 |
|
ships same day |
8 |
999-0335
|
Washer 1/4 x 5/8 SAE flat stainless steel |
$0.99
|
4 |
|
ships same day |
9 |
999-0181
|
Nut 1/4-20 hex jam plain finish |
$0.99
|
1 |
|
ships same day |
10 |
999-1083
|
Washer #8 internal star lock stainless steel |
$0.99
|
2 |
|
ships same day |
11 |
999-0497
|
Nut M6-1 nylon insert lock stainless steel |
$0.99
|
3 |
|
ships same day |
12 |
275-7079
|
36V contactor assembly |
$474.32
|
1 |
|
usually ships 10-16 days |
13 |
275-7080
|
Wire assembly |
$29.59
|
1 |
|
usually ships 1-5 days |
14 |
275-7081
|
Battery harness |
$121.66
|
1 |
|
usually ships 1-5 days |
