| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
273-6799
|
Squeegee retainer bracket |
1 |
|
|
2a |
273-6615
|
Squeegee blade |
2 |
|
|
2b |
991-9273
|
23 1/2 inch squeegee blade urethane |
2 |
|
|
3 |
273-6800
|
24 inch squeegee weldment |
1 |
|
|
4 |
273-0022
|
Screw 5/16-8 x 1 3/4 hex cap stainless steel |
2 |
|
|
5 |
999-0552
|
Bolt 5/16-18 x 1 1/2 hex head stainless steel |
2 |
|
|
6 |
999-0896
|
Screw 10-32 x 3/8 round head phillips stainless steel |
4 |
|
|
7 |
173-1481
|
Clevis pin |
2 |
|
|
8 |
173-1634
|
Bushing |
2 |
|
|
9 |
173-1630
|
3 inch rubber wheel |
2 |
|
|
10 |
173-3028
|
Roller wheel |
2 |
|
|
11 |
173-3985
|
Washer 7/16 flat stainless steel |
2 |
|
|
12 |
173-1480
|
Cotter ring |
2 |
|
|
13 |
999-0593
|
Nut 5/16-18 hex stainless steel |
2 |
|
|
14 |
273-6801
|
24 inch squeegee assembly |
1 |
(complete) |
|
