G2800 XC Cylinder Head Assembly

#PartDescriptionPriceReqNotesAvailability
1 273-9468 Thermal valve cover short $2.35 1 usually ships 7-19 days
2 273-9469 Valve screw $7.12 1 usually ships 7-19 days
3 273-9470 O-ring seal $2.49 1 usually ships 7-19 days
4 273-9471 O-ring seal $2.97 1 usually ships 7-19 days
5 273-9472 Thermo valve tin $14.25 1 usually ships 7-19 days
6 273-9473 Helical Spring $1.57 1 usually ships 7-19 days
7 273-9474 Unloader assembly $21.23 1 ships same day
8a 273-9475 Nozzle $2.35 1 (includes 8b) usually ships 7-19 days
8b 273-7976 Gasket $4.48 2 usually ships 7-19 days
9a 273-9476 Chemistry set $52.03 1 (includes 9b-9h) usually ships 7-19 days
9b 273-9806 Helical spring $3.08 1 usually ships 7-19 days
9c 273-9810 Chemistry nipple $4.74 1 usually ships 7-19 days
9d 273-9208 Sleeve $1.45 1 usually ships 7-19 days
9e 273-0476 O-ring seal $1.94 1 usually ships 7-19 days
9f 273-9809 O-ring seal $2.49 1 usually ships 7-19 days
9g 273-0560 Gasket $2.56 1 usually ships 7-19 days
9h 273-0475 Sphere $0.99 1 usually ships 7-19 days
10a 273-9444 Drain plug $13.53 3 (includes 10b) usually ships 7-19 days
10b 273-2084 O ring seal $2.49 1 usually ships 7-19 days
11a 273-9442 Pressure check valve set $25.19 1 (includes 11b) usually ships 7-19 days
11b 273-0215 Gasket $2.73 3 usually ships 1-5 days
12 273-9477 Valve (pkg of 3) $37.51 1 usually ships 7-19 days
13 273-9441 Plate $1.50 1 usually ships 7-19 days
14 273-9478 Cylinder head $87.99 1 usually ships 7-19 days
15 999-9079 Screw M8 x 80mm hex head stainless steel $4.41 4 ships same day
16 273-0438 Tension spring clamp $1.64 1 usually ships 7-19 days
