| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
999-9169
|
Screw M4-0.7 x 40mm pan head ss |
3 |
|
|
2 |
273-5499
|
Screw M4 x 10mm button head socket cap |
3 |
|
|
3 |
273-8785
|
Brs 43/500 frame cover |
1 |
|
|
4 |
273-5464
|
Single motor frame |
1 |
|
|
5 |
273-5463
|
iCapsol mini tray |
1 |
|
|
6 |
173-8641
|
Promax jet 11001 |
1 |
|
|
7 |
173-2210
|
Jet body |
1 |
|
|
8 |
173-8642
|
Sprayer manifold |
1 |
|
|
9 |
173-4999
|
Hose barb 1/8 x 1/4 |
1 |
|
|
10 |
173-2741
|
Hose clamp |
1 |
|
|
11 |
273-5468
|
Screw M6 x 8mm set |
1 |
|
|
12 |
273-5446
|
Screw M4 x 20mm pan head phillips |
1 |
|
|
13 |
273-5465
|
Nut M4 x .7 x 3mm u-clamp |
1 |
|
|
14 |
273-5466
|
Dome assembly |
1 |
|
|
15 |
273-7177
|
Splash guard plate (OBSOLETE) |
1 |
|
|
16 |
273-5452
|
Screw M5 x 10mm button socket head |
1 |
|
|
