| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
999-0972
|
Washer M14 flat |
2 |
|
|
2a |
373-9033
|
17 inch bumper |
1 |
(17 inch) (includes 10) |
|
2b |
373-9034
|
20 inch bumper |
1 |
(20 inch) (includes 10) |
|
3 |
373-9035
|
Left hand bumper cap |
1 |
|
|
4 |
373-9036
|
Right hand bumper cap |
1 |
|
|
5 |
173-4664
|
Wheel (gray) |
2 |
|
|
6 |
173-2834
|
Nut 1/2 flat push |
2 |
|
|
7 |
273-5003
|
Screw |
2 |
|
|
8 |
N/A
|
Not available |
2 |
(screw M6 x 20) |
|
9a |
N/A
|
Not available |
1 |
(20 inch chassis) (includes axle) |
|
9b |
373-9037
|
17 inch floor machine chassis |
1 |
(17 inch) (includes axle) |
|
10 |
373-9038
|
Slider tube link |
2 |
(after SN 10090950000488) (after SN 10090960000196) (after SN 10090970000096) |
|
11 |
173-2841
|
Handle adjustment link |
2 |
|
|
