ARMADA BRC 40/22 (GRAY) Solution Tank Assembly-Model 1.008-060.0

#PartDescriptionPriceReqNotesAvailability
1 999-6703 Screw 8-32 x 2 1/4 pan head phillips stainless steel $0.99 1 usually ships 11-24 days
2a 273-8506 Pump assemlby $507.10 1 (before SN 10080600001131) usually ships 7-19 days
2b 273-8505 Pump assemlby $343.30 1 (after SN 10080600001129) usually ships 7-19 days
3 273-8507 Coupling $23.21 1 usually ships 7-19 days
4 999-0151 Nut 8-32 nylon insert lock zinc plated $1.10 1 ships same day
5 273-8508 Bearing $71.50 1 usually ships 7-19 days
6 273-8509 Hose $4.96 1 usually ships 7-19 days
7 273-8510 Hose $6.16 27 usually ships 7-19 days
8 273-8511 Washer $7.32 1 usually ships 7-19 days
9 273-8440 Screw (OBSOLETE) $5.48 1 usually ships 7-19 days
10 273-8512 Hose $8.80 1 usually ships 7-19 days
11 173-9064 Seal $4.84 1 usually ships 7-19 days
12 173-5810 Nut 1/2 hex $5.08 1 usually ships 7-19 days
13 273-8513 Solution tank base $115.50 1 usually ships 7-19 days
14 273-7860 3/8 tube elbow $34.33 2 usually ships 7-19 days
15 273-7858 Elbow $28.93 1 usually ships 7-19 days
16 273-7859 Elbow $35.21 3 usually ships 7-19 days
17 273-8514 Solution tank lid assembly $62.16 1 (includes 28-29) (when replacing lid do not reuse gasket 28) usually ships 7-19 days
18 273-8515 Tube assembly $105.05 1 (includes 1pc each of 6-7) usually ships 7-19 days
19 273-7892 Washer 1/2 x 1 neoprene $6.77 1 usually ships 7-19 days
20 273-3820 11 inch cable tie $0.41 2 ships same day
21 173-7218 Hose clamp (OBSOLETE) $0.99 1 usually ships 1-5 days
22 273-8516 Strainer assembly $37.40 1 (includes 25-27) usually ships 7-19 days
23 273-8517 Connection $10.89 1 usually ships 7-19 days
24 273-1128 Angle bushing $37.29 1 usually ships 7-19 days
25 273-6141 Strainer cap $17.27 1 usually ships 7-19 days
26 173-3050 O-ring gasket $6.49 1 usually ships 7-19 days
27 273-8518 Screen $0.99 1 usually ships 7-19 days
28 273-8519 Gasket $13.31 1 ships same day
29 273-7314 Gasket $6.55 1 usually ships 7-19 days
N/S 273-8469 Adapter $10.01 1 usually ships 7-19 days
