KM 105/100 R Gas Set Assembly-Model 1.280-140.0

#PartDescriptionPriceReqNotesAvailability
1 373-4188 Safety lock decal $27.72 1 usually ships 14-22 days
2 373-4856 Decal Call for price 1 usually ships 14-22 days
3 373-4182 Bolt set Call for price 2 usually ships 14-22 days
4 373-4178 Hook sheet metal component Call for price 1 usually ships 14-22 days
5 373-4176 Sheet metal component Call for price 1 usually ships 14-22 days
6 373-4190 Fastener snap $33.03 1 usually ships 14-22 days
7 373-4191 Linch pin $2.51 1 usually ships 14-22 days
8 373-4175 Bolt Call for price 2 usually ships 14-22 days
10 183-0261 Screw (obsolete) $4.53 2 usually ships 1-5 days
11 173-9042 Washer #5 $1.40 2 usually ships 1-5 days
12 183-4190 Nut hex $1.35 2 usually ships 15-28 days
13 373-4189 Rope with loops $4.95 1 usually ships 14-22 days
14 373-4932 LPG bolt positioning Call for price 1 usually ships 14-22 days
16 999-1297 Screw M8 x 50mm hex head stainless steel $2.86 1 ships same day
18 373-4192 Holder $2.27 1 usually ships 14-22 days
