CV 66/2 Housing Assembly-Model 1.012-533.0

#PartDescriptionPriceReqNotesAvailability
1 273-6373 Cargo net $100.65 1 usually ships 14-22 days
2 273-6374 Tree fastener clip $5.50 11 usually ships 1-5 days
3 273-6375 Screw M8-1.25 x 25mm flat head (black) $4.72 6 usually ships 1-5 days
4 273-6376 Hinge $35.27 2 usually ships 1-5 days
5 273-6377 Glide rail $82.50 1 usually ships 1-5 days
6 273-6378 Hinged mounting bracket $108.35 1 usually ships 1-5 days
7 999-1267 Washer M8 flat zinc $0.99 4 ships same day
8 999-0028 Washer 5/16 split lock plain finish $0.99 2 ships same day
9 173-9344 Screw M8 x 20 hex $3.04 2 usually ships 1-5 days
10 273-4427 Body (gray) $391.60 1 (grey) usually ships 14-22 days
11 273-6380 Bracket $4.95 2 usually ships 1-5 days
12 273-4428 Screw M5-.8 x 10mm pan head phillips (black) $4.96 2 usually ships 14-22 days
13 273-5001 Screw $2.30 2 usually ships 14-22 days
14 999-1427 Screw M8-1.25 x 20mm button head stainless steel $1.43 2 ships same day
