| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
273-3400
|
Left side battery stop |
1 |
|
|
2 |
273-3401
|
Right side battery stop |
1 |
|
|
3 |
173-5977
|
Bearing sleeve |
2 |
|
|
4 |
273-3402
|
Shim plate |
2 |
|
|
5 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
4 |
|
|
6 |
999-0688
|
Bolt 5/16-18 x 1 1/4 hex head stainless steel |
2 |
|
|
7 |
173-4807
|
Washer #10 flat pleated (OBSOLETE) |
2 |
|
|
8 |
273-3403
|
Round standoff |
2 |
|
|
9 |
273-6867
|
Standoff |
2 |
|
|
10 |
273-3404
|
Left side spring mounting bracket |
1 |
|
|
11 |
273-3405
|
Right side spring mounting bracket |
1 |
|
|
12 |
173-5617
|
Spring |
2 |
|
|
13 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
2 |
|
|
14 |
999-1099
|
Bolt 1/4-20 x 3/4 hex head stainless steel |
2 |
|
|
