| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
173-8288
|
Latch |
1 |
|
|
2 |
999-0447
|
Screw 6-32 x 1/2 pan head phillips zinc plated |
2 |
|
|
3 |
173-5037
|
Nut 6-32 elastic stop (OBSOLETE) |
2 |
|
|
4 |
273-6281
|
Deck cover |
1 |
|
|
5 |
273-6282
|
Foam spacer |
2 |
|
|
6 |
273-6283
|
Foam spacer |
1 |
|
|
7 |
173-4807
|
Washer #10 flat pleated (OBSOLETE) |
1 |
|
|
8 |
173-3889
|
Screw 10 x 3/8 pan head hi/lo |
1 |
|
|
9 |
173-2797
|
Rivet |
2 |
|
|
