| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
173-5663
|
Quick disconnect coupler |
3 |
|
|
2 |
173-5664
|
45 inch pulse hose |
1 |
|
|
3 |
173-4934
|
Branch tee |
2 |
|
|
4 |
173-5677
|
45 degree elbow 1/4 x 1/4 |
1 |
|
|
5 |
173-5303
|
Solenoid valve |
1 |
|
|
6 |
173-5667
|
Solenoid coil |
1 |
|
|
7 |
173-5668
|
Bushing |
1 |
|
|
8 |
173-5304
|
Chemical injector valve kit |
1 |
|
|
9 |
173-5678
|
45 degree elbow 1/8 x 1/4 |
1 |
|
|
10 |
173-5679
|
Hose 3/16 x 8 |
1 |
|
|
11 |
173-5675
|
Nipple 3/8 x 1/4 |
2 |
|
|
12 |
173-3968
|
Screw 10-24 x 1/2 hex head stainless steel |
2 |
|
|
13 |
999-0998
|
Washer #10 flat stainless steel |
2 |
|
|
14 |
999-0697
|
Screw 8-32 x 3/4 pan head phillips stainless steel |
2 |
|
|
15 |
173-5672
|
115V terminal block |
1 |
|
|
16 |
999-1044
|
Screw 10-32 x 3/4 pan head phillips stainless steel |
2 |
|
|
17 |
173-5648
|
Quick disconnect nipple |
1 |
|
|
18 |
173-2472
|
Nut 10-32 with star washer |
4 |
|
|
19 |
173-2741
|
Hose clamp |
1 |
|
|
20 |
173-5673
|
Hose 1/4 ID x 41 inch nylon braid |
1 |
|
|
21 |
273-3820
|
11 inch cable tie |
6 |
|
|
22 |
173-5674
|
30 inch pulse hose |
1 |
|
|
