| # | Part | Description |
Req | Notes | Availability |
|---|
1 |
173-2741
|
Hose clamp |
3 |
|
|
2 |
273-0042
|
Nylon braided hose 1/4 x 23 inch |
2 |
|
|
3 |
173-8598
|
Chemical feed cap |
2 |
|
|
4 |
273-0057
|
Chemical metering valve |
1 |
|
|
5 |
173-2472
|
Nut 10-32 with star washer |
2 |
|
|
6 |
173-5647
|
10amp circuit breaker |
1 |
|
|
7 |
273-5447
|
8amp circuit breaker |
1 |
|
|
8 |
173-5648
|
Quick disconnect nipple |
1 |
|
|
9 |
173-1928
|
Elbow |
1 |
|
|
10 |
173-5162
|
Washer 5/8 x 1/2 inch |
3 |
|
|
11 |
173-2807
|
Screw 10-32 x 3/4 pan head phillips hi-lo |
4 |
|
|
12 |
173-5649
|
Switch control panel |
1 |
|
|
13 |
991-8158
|
1/4 inch BH2-60 female coupler (mate to QD40) |
1 |
|
|
14 |
189-0312
|
3/8 inch circuit breaker boot |
2 |
|
|
15 |
173-2174
|
3 position rocker switch |
1 |
|
|
16 |
173-4358
|
Switch gasket |
2 |
|
|
17 |
273-8956
|
2 position rocker switch |
1 |
|
|
