| # | Part | Description | Price | Req | Notes | Availability |
|---|
1 |
173-1593
|
Cotter ring (OBSOLETE) |
$0.99
|
2 |
|
usually ships 14-22 days |
2 |
173-4079
|
Actuator mount bracket |
$94.05
|
1 |
|
usually ships 1-5 days |
3 |
999-0423
|
Nut 5/16-18 nylon insert lock stainless steel |
$0.99
|
6 |
|
ships same day |
4 |
173-1598
|
24V actuator |
$750.20
|
1 |
|
usually ships 14-22 days |
5 |
173-0505
|
Bushing |
$5.50
|
3 |
|
usually ships 1-5 days |
6 |
173-1577
|
Tree clip |
$5.61
|
4 |
|
usually ships 14-22 days |
7 |
173-4081
|
Brush release cover |
$23.14
|
2 |
|
usually ships 1-5 days |
8 |
173-4082
|
Clevis pin |
$11.77
|
1 |
|
usually ships 1-5 days |
9 |
173-4083
|
Clevis pin |
$2.06
|
1 |
|
usually ships 1-5 days |
10 |
173-4084
|
Ext. skirt |
$86.35
|
1 |
|
usually ships 1-5 days |
11 |
173-4085
|
Right skirt strap |
$73.15
|
1 |
|
usually ships 1-5 days |
12 |
999-0333
|
Screw 10-24 x 1/2 pan head phillips stainless steel |
$0.99
|
8 |
|
ships same day |
13 |
999-1504
|
Nut 10-24 jam insert lock stainless steel |
$0.99
|
8 |
|
ships same day |
14 |
173-4087
|
Bumper wheel mount bracket |
$40.37
|
1 |
|
usually ships 1-5 days |
15 |
173-1630
|
3 inch rubber wheel |
$5.50
|
1 |
|
ships same day |
16 |
173-1634
|
Bushing |
$11.55
|
1 |
|
usually ships 14-22 days |
17 |
999-0893
|
Screw 5/16-18 x 2 hex head stainless steel |
$0.99
|
1 |
|
ships same day |
18 |
173-4088
|
Nut 5/16-18 hex coupling stainless steel |
$30.58
|
1 |
|
usually ships 14-22 days |
19 |
173-4089
|
Gas spring ball stud |
$17.27
|
2 |
|
usually ships 1-5 days |
20 |
999-0549
|
Washer 5/16 x 3/4 SAE flat stainless steel |
$0.99
|
3 |
|
ships same day |
21 |
173-4090
|
Gas spring |
$226.60
|
1 |
|
usually ships 1-5 days |
